ADE9000 Technical Reference Manual
Address Name
0x323 BWATTHR_HI
0x32B BVAR_ACC
0x32C BVARHR_LO
0x32D BVARHR_HI
0x335 BVA_ACC
0x336 BVAHR_LO
0x337 BVAHR_HI
0x33F BFWATT_ACC
0x340 BFWATTHR_LO
0x341 BFWATTHR_HI
0x349 BFVAR_ACC
0x34A BFVARHR_LO
0x34B BFVARHR_HI
0x353 BFVA_ACC
0x354 BFVAHR_LO
0x355 BFVAHR_HI
0x35D CWATT_ACC
0x35E CWATTHR_LO
0x35F CWATTHR_HI
0x367 CVAR_ACC
0x368 CVARHR_LO
0x369 CVARHR_HI
0x371 CVA_ACC
0x372 CVAHR_LO
0x373 CVAHR_HI
0x37B CFWATT_ACC
0x37C CFWATTHR_LO
0x37D CFWATTHR_HI
0x385 CFVAR_ACC
0x386 CFVARHR_LO
Description
Phase B accumulated total active energy, MSB. Updated according to the settings
in the EP_CFG and EGY_TIME registers.
Phase B accumulated total reactive power, updated after PWR_TIME 8 kSPS samples.
Phase B accumulated total reactive energy, LSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated total reactive energy, MSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated total apparent power, updated after PWR_TIME 8 kSPS samples.
Phase B accumulated total apparent energy, LSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated total apparent energy, MSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated fundamental active power, updated after PWR_TIME 8 kSPS
samples.
Phase B accumulated fundamental active energy, LSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated fundamental active energy, MSB. Updated according to the
settings in EP_CFG and EGY_TIME registers.
Phase B accumulated fundamental reactive power, updated after PWR_TIME 8 kSPS
samples.
Phase B accumulated fundamental reactive energy, LSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated fundamental reactive energy, MSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated fundamental apparent power, updated after PWR_TIME 8 kSPS
samples.
Phase B accumulated fundamental apparent energy, LSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated fundamental apparent energy, MSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Phase C accumulated total active power, updated after PWR_TIME 8 kSPS samples.
Phase C accumulated total active energy, LSB. Updated according to the settings
in the EP_CFG and EGY_TIME registers.
Phase C accumulated total active energy, MSB. Updated according to the settings
in the P_CFG and EGY_TIME registers.
Phase C accumulated total reactive power, updated after PWR_TIME 8 kSPS samples.
Phase C accumulated total reactive energy, LSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase C accumulated total reactive energy, MSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase C accumulated total apparent power, updated after PWR_TIME 8 kSPS samples.
Phase C accumulated total apparent energy, LSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase C accumulated total apparent energy, MSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase C accumulated fundamental active power, updated after PWR_TIME 8 kSPS
samples.
Phase C accumulated fundamental active energy, LSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase C accumulated fundamental active energy, MSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase C accumulated fundamental reactive power, updated after PWR_TIME 8 kSPS
samples.
Phase C accumulated fundamental reactive energy, LSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Rev. 0 | Page 59 of 86
UG-1098
Reset Access
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
