MATERIALS

Materials supplied with this kit

NTI RACKMUX-DS17-N(T)-xDVIHD KVM Drawer with USB KVM Switch (where x= 4,8 or 16)

Line cord, country specific

Set of keys for keylock

2 Rear Mounting Brackets w/ 4 nuts

8pcs #10-32x3/4" screws and cage nuts for mounting to a rack

URL slip with address to pdf of this manual

1- DB9 Female-to-RJ45 Female adapter

1- 5 foot RJ45-to-RJ45 CAT5 patch cable
Materials Not supplied but REQUIRED:

USB-DHEXT-xx-MM cable for each CPU being connected to the switch- for DVI monitor, USB keyboard, and USB mouse
support- available in 3, 6,10, and 15 foot lengths
where:
xx is the length of the cable in feet
MM indicates male-to-male connector
Cables can be purchased from Network Technologies Inc by calling (800) 742-8324 (800-RGB-TECH) in the US and Canada or
(330) 562-7070 (worldwide).
DVI-D-Male
Single Link
DVI-D-Male
USB Type A
USBType A Male
Male
:
USB-DHEXT-xx-MM
(3,6,10 and 15 foot cables available)
2
HDMI Type A
HDMI Type A Male
Male
