Trackball; Touchpad; Index; Warranty Information - NTI RACKMUX-DS17-NT-4DVIHD Installation And Operation Manual

NTI RACKMUX KVM Drawer with UNIMUX Switch

Trackball

Casing Material..............................................ABS
Ball Material ...................................................Phenolic (metal core)
Ball Color .......................................................Black
Ball Diameter .................................................16mm
Tracking Force...............................................10 grams nominal
Resolution......................................................117 pulse per ball revolution
Mounting Angle..............................................Max. 30' to horizontal plane
Lifetime-Ball Revolutions ...............................>= 1 million
Mechanical Buttons .......................................3 Mechanical switches are supported

Touchpad

Motion Detection Method ...............................Capacitance sensing
X/Y Position Sensing Resolution ...................40 counts/mm
X/Y Position Reporting...................................Relative (Similar to mouse)
Tracking Speed..............................................Up to 1016 mm/sec
Touch Force...................................................No Contact pressure required
Lifetime (Plastic Overlay) ...............................Minimum 10,000,000 strokes
Sample Rate ..................................................Up to 100 samples/sec

INDEX

addressing, 15
Autostatus, 17
baud rate, 14
Broadcast mode, 12
Command mode, 11
connect the cables, 9
country codes, 13
daisy-chaining, 15
Display functions, 20
Fn key, 23
front panel control, 11
keyboard control, 11
Keyboard LEDs, 23
LEDs, 23

WARRANTY INFORMATION

The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network
Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at
http://www.networktechinc.com/return-policy.html
is required for all repairs/returns.
Matrix-Y-1 cable, 15
OSD Controls, 20
OSD Menu-DVI, 21
power-up sequence, 10
Rack mounting, 4
RS232 commands, 16
RS232 Control, 14
RS232 pinout, 14
Scan mode, 12
SerTest, 18
Sun sleep mode, 13
Switch Control Program, 18
Telco mount, 8
for information regarding repairs and/or returns. A return authorization number
26
MAN082 Rev 7/6/18
