Figure 10-12:Timing Diagram: DIF Operation, Dual Trigger

Perform the following procedure to configure a dual trigger DIF experiment:
1. The PI-MAX4 camera must be aligned and focused on the area of interest for this
experiment. This is best accomplished while the PI-MAX4 is operating in Interline mode
(i.e., before switching to DIF mode.)
Verify that the
his field is located on the Setup —> Hardware Setup —> Controller/Camera tab. See
Figure

Figure 10-13:WinX Hardware Setup Dialog: Controller/Camera Tab

WinX and Dual Image Feature
FIRST FRAME
D1 W1
W1
REFERENCES:
Refer to Chapter 4, First
focusing of the camera.
Phosphor Decay Time
10-13.
SECOND FRAME
PD D2
Light, for information about the initial
is appropriate to the phosphor used by the camera.
