Supported Timing Generator Trigger Modes; Single Sequence; Figure 8-2: Timing Diagram: Trigger Per Pulse; Figure 8-3: Timing Diagrams: Three Repetition Sequence - Princeton Instruments PI-MAX4 Manual

154
8.1.1

Supported Timing Generator Trigger Modes

Trigger per Pulse:
See Figure

Figure 8-2: Timing Diagram: Trigger Per Pulse

TRIGGER
PULSES
EXPOSE
Supported Trigger Sources are:
•
•
8.2

Single Sequence

A sequence is the repetition of a single Pulse Set for X number of times.
illustrates a sequence with the pulse set repeated three (3) times.

Figure 8-3: Timing Diagrams: Three Repetition Sequence

The
EXPOSE
mately 15 ns after sequence completion.
®
PI-MAX
The pulse set is initiated by its own trigger (either internal or external.)
8-2.
CCD
Source 1: Timing Generator internal trigger
A pulse set is initiated by the timing generator's internal trigger.
Source 2: External Trigger (on TRIGGER IN BNC)
A pulse set is initiated by an external trigger.
PULSE SET
signal remains high for the duration of the sequence and goes low approxi-
4 System Manual
PULSE SET
EXPOSE
SEQUENCE (3 Repetitions)
PULSE SET PULSE SET
Issue 9
READOUT
4411-0139_0087
Figure 8-3
PULSE SET PULSE SET
4411-0139_0088
