Appendix G: Accessories

G.1 Accessory Kits
The camera is shipped with the adapter mount specified when it was purchased. If a kit for
an additional adapter mount is also purchased, it will be shipped in an accessory kit
containing a double-ended screwdriver with magnet top. When the additional adapter is a
spectroscopy mount adapter, a quick start guide will be provided which describes how to
mount the camera to Acton SpectraPro Series spectrograph. A similar quick start is shipped
when an IsoPlane spectrograph is ordered.
G.2 Adapter Kits
Refer to
accessory kit.

Table G-1: Adapter Kit Information

C-Mount Adapter
F-Mount Adapter
Spectroscopy-Mount Adapter
IVUV/NVUV
Spectroscopy-Mount Adapter
Figure G-1

Figure G-1: Magnetic Screwdriver with Reversible Flat and Phillips Bit

NOTE:
The quick start information for each type of spectrograph is
included in Appendix F, Spectrograph Mount
Table G-1 for information about available adapter kits that may be included in the
Kit
illustrates the reversible screwdriver that is included with the accessory kit.
Part Number
2530-0074 Adapter, 4-40x 7/16 flat head Phillips screws,
dust cover
2530-0076 Adapter, 4-40x 7/16 flat head Phillips screws,
dust cover
2530-0075 Adapter, 4-40x7/16 flat head Phillips screws,
dust cover
2530-0082 Adapter, 4-40x7/16 flat head Phillips screws,
o-ring (2.739" I.D.,) o-ring (2.614" I.D.,) dust
cover
Information.
Description/Contents
