Receive Packet 1519-2047 Statistics Counter (RX_PKT_1519_2047)
A read of the low byte of this counter returns that byte and latches the upper bytes for later reading. A read of any
of the other bytes returns the previously latched value for that byte. The low address addresses the low byte.
Table 5-68. Receive Packet 1519-2047 Statistics Counter Description
Name: RX_PKT_1519_2047
Bits Name
63:0 Packet 1519-2047
Receive Packet 2048-4095 Statistics Counter (RX_PKT_2048_4095)
A read of the low byte of this counter returns that byte and latches the upper bytes for later reading. A read of any
of the other bytes returns the previously latched value for that byte. The low address addresses the low byte.
Table 5-69. Receive Packet 2048-4095 Statistics Counter Description
Name: RX_PKT_2048_4095
Bits Name
63:0 Packet 2048-4095
Receive Packet 4096-9216 Statistics Counter (RX_PKT_4096_9216)
A read of the low byte of this counter returns that byte and latches the upper bytes for later reading. A read of any
of the other bytes returns the previously latched value for that byte. The low address addresses the low byte.
Table 5-70. Receive Packet 4096-9216 Statistics Counter Description
Name: RX_PKT_4096_9216
Bits Name
63:0 Packet 4096-9216
Receive Packet 9217-16383 Statistics Counter (RX_PKT_9217_16383)
A read of the low byte of this counter returns that byte and latches the upper bytes for later reading. A read of any
of the other bytes returns the previously latched value for that byte. The low address addresses the low byte.
Table 5-71. Receive Packet 9217-16383 Statistics Counter Description
Name: RX_PKT_9217_16383
Bits Name
Packet 9217-
63:0
16383
IPUG39_02.9, December 2010
Type Default
Counts the number of packets received that were between 1519-
RO — 2047 octets in length (including bad packets). rx_statvec[13:0] is
used to implement this counter.
Type Default
Counts the number of packets received that were between 2048-
RO — 4095 octets in length (including bad packets). rx_statvec[13:11] is
used to implement this counter.
Type Default
Counts the number of packets received that were between 4096-
RO — 9216 octets in length (including bad packets). rx_statvec[13:0] is
used to implement this counter.
Type Default
Counts the number of packets received that were between 9217-
RO — 16383 octets in length (including bad packets). rx_statvec[13:0] is
used to implement this counter.
44
Application Support
Address: 9e0H - 9e7H
Description
Address: 9e8H - 9efH
Description
Address: 9f0H - 9f7H
Description
Address: 9f8H - 9ffH
Description
