Lattice Semiconductor 10 Gb+ Ethernet MAC IP User Manual page 26

Lattice Semiconductor
Table 5-1. 10 Gb+ Ethernet MAC IP Core Internal Registers (Continued)
Register Description
FIFO Almost Full Register
FIFO Almost Full Register
FIFO Almost Empty Register
FIFO Almost Empty Register
Statistic Counters
TX Packet Length Statistics Counter
TX Error Statistics Counter
TX Underrun Statistics Counter
TX CRC Error Statistics Counter
TX Length Error Statistics Counter
TX Long Packet Statistics Counter
TX Multicast Packet Statistics Counter
TX Broadcast Packet Statistics Counter
Transmit Control Packet Statistics Counter
TX Jumbo Packet Statistics Counter
TX Pause Packet Statistics Counter
TX VLAN Tag Statistics Counter
TX Packet OK Statistics Counter
Transmit Packet 64 Statistics Counter
Transmit Packet 65-127 Statistics Counter
Transmit Packet 128-255 Statistics Counter
Transmit Packet 256-511 Statistics Counter
Transmit Packet 512-1023 Statistics Counter
Transmit Packet 1024-1518 Statistics Counter
Transmit Packet 1518 Statistics Counter
Transmit Frame Error Statistics Counter
Transmit Packet 1519-2047 Statistics Counter
Transmit Packet 2048-4095 Statistics Counter
Transmit Packet 4096-9216 Statistics Counter
Transmit Packet 9217-16383 Statistics Counter
Receive Packet Length Statistics Counter
RX VLAN Tag Statistics Counter
RX Pause Packet Statistics Counter
Receive Filtered Packet Statistics Counter
RX Unsupported Opcode Statistics Counter
RX Broadcast Packet Statistics Counter
RX Multicast Packet Statistics Counter
RX Length Error Statistics Counter
RX Long Packet Statistics Counter
RX CRC Error Statistics Counter
Receive Packet Discard Statistics Counter
Receive Packet Ignored Statistics Counter
Receive Packet Fragments Statistics Counter
IPUG39_02.9, December 2010
Internal Registers
Mnemonic
FIFOAFT_0
FIFOAFT_1
FIFOAET_0
FIFOAET_1
RX_STAT_PKT_LNGTH
TX_STAT_TX_ERR
TX_STAT_UNDER_RUN
TX_STAT_CRC_ERR
TX_STAT_LNGTH_ERR
TX_STAT_LNG_PKT
TX_STAT_MULTCST
TX_STAT_BRDCST
RX_STAT_CNT
TX_STAT_JMBO
TX_STAT_PAUSE
TX_STAT_VLN_TG
TX_STAT_PKT_OK
TX_STAT_PKT_64
TX_STAT_PKT_65_127
TX_STAT_PKT_128_255
TX_STAT_PKT_256_511
TX_STAT_PKT_512_1023
TX_STAT_PKT_1024_1518
TX_STAT_PKT_1518
TX_STAT_FRM_ERR
TX_STAT_PKT_1519_2047
TX_STAT_PKT_2048_4095
TX_STAT_PKT_4096_9216
TX_STAT_PKT_9217_16383
RX_STAT_PKT_LNGTH
RX_STAT_VLN_TG
RX_STAT_PAUSE
RX_STAT_FLT
TX_STAT_UNSP_OPCODE
RX_STAT_BRDCST
RX_STAT_MULTCST
RX_STAT_LNGTH_ERR
RX_STAT_LNG_PKT
RX_STAT_CRC_ERR
RX_PKT_DISCARD_STAT
RX_PKT_IGNORE
RX_PKT_FRAGMENTS
26 10 Gb+ Ethernet MAC IP Core User's Guide
Application Support
I/O Address Reset Value
B04H 01H
B05H 00H
B06H 00H
B07H 03H
800H 00H
808H 00H
810H 00H
818H 00H
820H 00H
828H 00H
830H 00H
838H 00H
840H 00H
848H 00H
850H 00H
858H 00H
860H 00H
868H 00H
870H 00H
878H 00H
880H 00H
888H 00H
890H 00H
898H 00H
8a0H 00H
8a8H 00H
8b0H 00H
8b8H 00H
8c0H 00H
900H 00H
908H 00H
910H 00H
918H 00H
920H 00H
928H 00H
930H 00H
938H 00H
940H 00H
948H 00H
950H 00H
958H 00H
960H 00H
