4-7-7-1 ►Serial Port 1 Confi guration & Serial Port 2 Confi guration
Main Advanced
Serial Port 1~2 Confi guration
Serial Port
Device Settings
Change Settings
COM1 422/485 control fl ow
COM2 422/485 control fl ow
Serial Port
Use this item to enable or disable serial port (COM).
The optional settings are: Enabled, Disabled.
Change Settings
Use this item to select an optimal setting for super IO device.
The optional settings are:
AUTO
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3,4,5,6,7,10,11,12;
IO=2F8h; IRQ=3,4,5,6,7,10,11,12;
IO=3E8h; IRQ=3,4,5,6,7,10,11,12;
IO=2E8h; IRQ=3,4,5,6,7,10,11,12;
COM1 422/485 control fl ow
Use this item to enable or disable serial port (COM) Autofl ow
The optional settings are: Enabled, Disabled.
4-7-8 F17869 H/W Monitor
F17869 H/W Monitor
Press [Enter] to view PC health status.
This section shows the status of your CPU, Fan, and overall system.
This is only available when there is Hardware Monitor function onboard.
Chipset
Boot
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Save & Exit
Security
[Enabled]
IO=3F8h; IRQ=4;
[AUTO]
[Disabled]
[Disabled]
63
Enable or Disable Serial
Port (COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
