4-4 Getting Help

Main Menu
The on-line description of the highlighted setup function is displayed at the top right corner
the screen.
Status Page Setup Menu/Option Page Setup Menu
Press F1 to pop up a small help window that describes the appropriate keys to use and
the possible selections for the highlighted item. To exit the Help Window, press <Esc>.

4-5 Menu Bars

There are six menu bars on top of BIOS screen:

Main

To change system basic confi guration
Advanced To change system advanced confi guration
Chipset To change chipset confi guration
Boot To change boot settings
Security Password settings
Save & Exit Save setting, loading and exit options.
User can press the right or left arrow key on the keyboard to switch from menu bar.
The selected one is highlighted.
4-6 Main
Main Advanced
BIOS Vendor
Processor Information
Name
Brand String
Frequency
Total Memory
Memory Frequency
System Date
System Time
Main menu screen includes some basic system information. Highlight the item and then use
the <+> or <-> and numerical keyboard keys to select the value you want in each item.
System Date
Set the Date. Please use [Tab] to switch between data elements.
System Time
Set the Time. Please use [Tab] to switch between data elements.
Chipset
Boot
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Save & Exit
Security
CI770C/A
IvyBridge
Intel(R) Core(TM) i7
2300 MHz
2048 MB (DDR3)
1333 MHz
[Tue 01/15/2013]
[19:28:51]
54
Set the date. Use Tab
to Switch between
date elements.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
