CO1: I C 4pin (1.25mm) wafer
LPT1: LPT 2x13 pin (2.0mm) wafer (option).
CPI1: DC 12V-in DIN external connector (4pin mini din connector)
CPI11: DC 12V-in internal connector (2x2pin 4.2mm ATX connector) (option).
CPI13: DC-in 2x4 pin (2.0mm) wafer connector.
CPO1: DC +5/+12V output connector (2.5mm) wafer.
CPO2: DC +5/+12V output connector (2.5mm) wafer.
CPO3: DC +5/+12V output 1x4 pin(2.0mm) wafer (option).
CU5: USB port 2 4pin(1.25mm) wafer (option).
CU6: USB port 3 4pin(1.25mm) wafer (option).
CU7: USB port 7 4pin(1.25mm) wafer.
CU8: USB port 8 4pin(1.25mm) wafer.
CU9: USB port 9 4pin(1.25mm) wafer. (The port share with touch device) (option).
CU10: USB port 10 4pin(1.25mm) wafer. (The port share with MPCE1) (option).
CU11: USB port 11 4pin(1.25mm) wafer. (The port share with MPCE2) (option).
CU12: USB port 12 4pin(1.25mm) wafer.
CU13: USB port 13 4pin(1.25mm) wafer.
CU14: USB port 14 4pin(1.25mm) wafer.
CUL1: USB port 3.0/2.0 3/4 and LAN1 RJ45 connector.
CUL2: USB port 3.0/2.0 1/2 and LAN2 RJ45 connector.
CFA1: CFast card socket 7+17pin (option).
SATA1: SATA port 1 (Gen III) connectors 7pin.
SATA2: SATA port 2 (Gen III) connectors 7pin.
SATA3: SATA port 3 connectors 7pin.
SATA4: SATA port 4 connectors 7pin.
MPCE1: Mini card port 1 sockets 52pin.
MPCE2: Mini card port 2 sockets 52pin.
SIM1: SIM port 1 card socket.
SIM2: SIM port 2 card socket.
CFP1: Front panel port 2x5 pin (2.54mm) wafer.
SWP1: Power On/Off switch wafer.
FAN1: CPU fan 1x3 pin (2.54mm) wafer.
FAN2: System fan 1x3 pin (2.54mm) wafer.
SODIM1/2: SO-DIM DDR3 1.5V DRAM Socket
