Display

The road signs detected by Dynamic Road Sign Display system are displayed on the instrument cluster

navigation system installed in the vehicle, also on the infotainment system display. Depending on the equipment level, a notification may also

→ Instrument cluster

appear on the Head-up Display

Dynamic Road Sign Display texts

No road signs available

Error: Dynamic Road Sign Display

Speed warning currently not available.

Dynamic Road Sign Display: clean windscreen!

Dynamic Road Sign Display is currently restricted.

No data available

Switching Dynamic Road Sign Display on and off in the instrument cluster display

The continuous display of road signs in the instrument cluster display can be activated and deactivated using the

Driver assistance

and

function buttons.

Display of road signs

After checking and evaluation of the information from the camera, the navigation system and the current vehicle data, up to three valid road

→ Fig. 53

signs

with the accompanying additional signs will be displayed:

1st position: The road sign that currently applies for the driver is shown on the left-hand side of the display, e.g. a speed limit of 130 km/h

(100 mph)

→ Fig. 53

. 2nd position: Road signs that do not always apply (e.g. 100 km/h (60 mph) in wet conditions

sign: if the windscreen wiper is active while the vehicle is in motion, any road sign, for example with the additional In wet conditions sign that now

applies will be moved left to the first position. 3rd position: Further road signs that do not always apply will be displayed in the third position, e.g.

overtaking temporarily not permitted

→ Fig. 53

The sign is shown steadily in the instrument cluster display when you drive past the road sign.

Shortly after driving into or out of an urban area, the speed limits that normally apply to urban and/or rural roads in the country in which you are

travelling will be displayed. If there is an additional road sign displaying a speed limit on the way into or out of the urban area, this sign will be

shown in the display.

Signs indicating the end of a speed limit or overtaking restriction will not be displayed.

There is no warning when you exceed the displayed speed limits. Traffic-calmed areas are not detected by the system. The legal regulations

apply.

Speed warning function

When the Dynamic Road Sign Display detects that an applicable speed limit has been exceeded, it will issue an acoustic warning signal and

display a message on the instrument cluster display.

The speed warning can be activated or completely deactivated using the

buttons in the infotainment system. The settings can be adjusted in increments of 5 km/h (3 mph) within a range between 0 km/h (mph) and 15

km/h (9 mph) above the permitted maximum speed.

Trailer mode

In vehicles with a factory-fitted towing bracket and an electrical connection to the vehicle, the display of traffic signs that may apply to the vehicle

Cause and solution

The system is in the initialisation phase.

OR: the camera has not detected any regulatory or warning signs.

System fault.

Go to a qualified workshop and have the system checked.

Fault in the Dynamic Road Sign Display system speed warning.

Go to a qualified workshop and have the system checked.

The area around the camera on the windscreen is dirty.

Clean the windscreen.

No data transmission from the navigation system.

Check whether valid map data is loaded on the navigation system.

OR: the vehicle is located in an area that is not covered by the map
