2014 Volkswagen Tiguan
Quick Reference Specification Book

TaBle of ConTenTS

General Information ...................................................... 1
Decimal and Metric Equivalents ...........................................1
Distance/Length ....................................................................1
Tightening Torque .................................................................2
Nm-to-lb·ft (ft·lb) ...................................................................2
Nm-to-lb·in (in·lb), kg·cm ......................................................3
N·cm-to-lb·in (in·lb), kg·cm ...................................................3
kg·cm-to-lb·in (in·lb), N·cm ...................................................4
Warnings and Cautions ........................................................4
WARNINGS ..........................................................................4
CAUTIONS ...........................................................................7
Vehicle Identification ..................................................... 9
VIN Decoder ..........................................................................10
Sales Codes ................................................................. 12
Engine Codes ........................................................................12
Transmission Codes ..............................................................12
Vehicle Lifting .............................................................. 13
Hoist and Jack Mounting Points .........................................13
Front ......................................................................................13
Rear .......................................................................................14
CHASSIS
Suspension, Wheels, Steering ................................... 16
Front Suspension ...............................................................16
Wheel Bearing Overview .......................................................18
Driveshaft with CV joint VL107 Overview ..............................22
VW Tiguan Quick Reference Specification Book • February 2014
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tiguan 2014 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volkswagen Tiguan 2014

Summary of Contents for Volkswagen Tiguan 2014

  • Page 1: Table Of Contents

    2014 Volkswagen Tiguan Quick Reference Specification Book TaBle of ConTenTS General Information ............1 Decimal and Metric Equivalents ...........1 Distance/Length ..............1 Tightening Torque ..............2 Nm-to-lb·ft (ft·lb) ..............2 Nm-to-lb·in (in·lb), kg·cm ............3 N·cm-to-lb·in (in·lb), kg·cm ...........3 kg·cm-to-lb·in (in·lb), N·cm ...........4 Warnings and Cautions ............4 WARNINGS ................4...
  • Page 2 Rear Suspension ..............28 Subframe Transverse Link and Tie Rods FWD Overview ..28 Left Rear Level Control System Sensor -G76- FWD Overview .................30 Wheel Bearing Housing, Trailing Arm FWD Overview ...32 Shock Absorber, Coil Spring FWD Overview ......34 Stabilizer Bar FWD Overview ..........35 Subframe, Final Drive AWD Overview ........36 Left Rear Level Control System Sensor -G76- AWD Overview .................37...
  • Page 3 Anti-lock Brake System (ABS) ..........64 Control Module and Hydraulic Unit Overview ......64 Front Axle ABS Components Overview .........65 Rear Axle ABS Components, FWD Overview .......66 Rear Axle ABS Components, AWD ........67 Mechanical Components ...........68 Front Wheel Brakes FN 3 Assembly Overview ......68 Rear Brakes CII 41 Assembly Overview ........70 Brake Pedal Assembly Overview ...........72 Hydraulic Components ............73...
  • Page 4 Door Hinge Assembly Overview ..........106 Subframe Assembly Overview ..........108 Door Handle and Door Lock Assembly Overview ....109 Sunroof ................110 Panorama Sunroof Assembly Overview ......110 Assembly Frame Overview ..........111 Sunroof Tightening Specifications ........113 Bumpers ................114 Front Bumper Cover Assembly Overview ......114 Front Bumper Carrier Assembly Overview ......
  • Page 5 Heating, Ventilation ............135 Fastener Tightening Specifications ........135 Air Conditioning ..............136 Fastener Tightening Specifications ........136 Electrical System ............138 Electrical Equipment ............138 Battery, Starter, Generator, Cruise Control .......138 Battery Overview ..............138 Generator Overview ............140 Starter Overview ..............142 Windshield Wiper/Washer System ........143 Rear Window Wiper System Overview ........143 Windshield Wiper System Overview ........144 Windshield Wiper/Washer System Tightening...

  • Page 7: General Information

    GEnErAL InformAtIon Decimal and Metric Equivalents Distance/Length To calculate: mm x 0.03937 = in. 0.002 0.00008 0.01 0.0004 0.004 0.04 0.004 0.00016 0.02 0.0008 0.008 0.08 0.006 0.00024 0.03 0.0012 0.012 0.12 0.008 0.00031 0.04 0.0016 0.016 0.16 0.010 0.00039 0.05 0.0020 0.020...

  • Page 8: Tightening Torque

    Tightening Torque nm-to-lb·ft (ft·lb) To calculate: Nm x 0.738 = lb·ft lb·ft lb·ft lb·ft (ft·lb) (ft·lb) (ft·lb) VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 9: Nm-To-Lb·in (In·lb), Kg·cm

    nm-to-lb·in (in·lb), kg·cm To calculate: Nm x 8·85 = lb·in • Nm x 10.20 = kg·cm lb·in lb·in kg·cm kg·cm (in·lb) (in·lb) n·cm-to-lb·in (in·lb), kg·cm To calculate: N·cm x 0.089 = lb·in • N·cm x 0.102 = kg·cm lb·in lb·in n·cm kg·cm n·cm...

  • Page 10: Kg·cm-To-Lb·in (In·lb), N·cm

    kg·cm-to-lb·in (in·lb), n·cm To calculate: kg·cm x 0.868 = lb·in • kg·cm x 9.81 = N·cm lb·in lb·in kg·cm n·cm kg·cm n·cm (in·lb) (in·lb) 1079 1177 1275 1373 1471 1569 1667 1765 1863 1961 2059 2157 2256 2354 2452 Warnings and Cautions WArnInGS •...
  • Page 11 • Never run the engine unless the work area is well ventilated. Carbon monoxide kills. • Remove rings, bracelets and other jewelry so they cannot cause electrical shorts, get caught in running machinery, or be crushed by heavy parts. • Tie back long hair. Do not wear a necktie, a scarf, loose clothing, or a necklace when you work near machine tools or running engines.
  • Page 12 WArnInGS (cont’d) • Batteries give off explosive hydrogen gas during charging. Keep sparks, lighted matches and open flame away from the top of the battery. If hydrogen gas escaping from the cap vents is ignited, it ignites the gas trapped in the cells and causes the battery to explode.

  • Page 13: Cautions

    • Place jack stands only at locations specified by manufacturer. The vehicle lifting jack supplied with the vehicle is intended for tire changes only. Use a heavy duty floor jack to lift the vehicle before installing jack stands. • Battery acid (electrolyte) can cause severe burns. Flush contact area with water, seek medical attention.
  • Page 14 CAUtIonS (cont’d) • Label battery cables before disconnecting. On some models, battery cables are not color coded. • Disconnecting the battery may erase fault code(s) stored in control module memory. Check for fault codes prior to disconnecting the battery cables. •...

  • Page 15: Vehicle Identification

    VEHICLE IDEntIfICAtIon Vehicle Identification Number (VIN) Location The VIN ( Æ ) is on the left side of the vehicle in the area of the windshield wiper mount. It is visible from the outside (typical illustration shown). VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 16: Vin Decoder

    VIn Decoder 2014 Volkswagen VIN Decoder (except Routan) Series: k= Jetta SportWagen w/5 A= CC Sport w/Man Trans, Spd Man Trans Passat S, Tiguan w/Auto E = 2014 L= Jetta SEL/TDI w/Auto Trans Trans B= CC Sport/Sport+ w/Auto m= Jetta SportWagen w/6...
  • Page 17 Vehicle Identification Number (VIN) The engine number “engine code” and “serial number” are located at the engine/transmission joint. The engine code is also printed behind the oil filter on the cylinder block. Vehicles with four Digit Engine Codes Four digit engine codes beginning with the letter “C” are used. The first three digits describe the mechanical structure of the engine and are still stamped on the engine, as before.

  • Page 18: Sales Codes

    SALES CoDES Engine Codes CCtA 2.0L 4-cylinder transmission Codes 6-speed manual 6-speed automatic VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 19: Vehicle Lifting

    VEHICLE LIftInG Hoist and Jack Mounting Points front Position the support plate in the side member vertical reinforcement area ( Æ VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 20: Rear

    rear Position the support plate in the side member Æ vertical reinforcement area ( VW Tiguan Quick Reference Specification Book • February 2014...
  • Page 21 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 22: Suspension, Wheels, Steering

    SUSpEnSIon, WHEELS, StEErInG Front Suspension Subframe, Stabilizer Bar and Control Arms overview 1 - nut 65 Nm … Allways replace if removed … 2 - Stabilizer Bar There are different versions … 3 - Coupling rod 4 - nut 65 Nm …...
  • Page 23 7 - Bolt 70 Nm +180° turn … M12 x 1.5 x 100 … Allways replace if removed … 8 - Control Arm 9 - nut 60 Nm … M12 x 1.5 … Allways replace if removed … 10 - Ball Joint 11 - nut Aluminum control arm: 60 Nm …...

  • Page 24: Wheel Bearing Overview

    Wheel Bearing overview 1 - Suspension Strut 2 - Internal multi-point Bolt 3 - Left front ABS Wheel Speed Sensor -G47-/right front ABS Wheel Speed Sensor -G45- 4 - Hex Socket Head Bolt 8 Nm … M6 x 16 … 5 - tie rod End 6 - Wheel Hub with Wheel Bearing 7 - nut...
  • Page 25 9 - Bolt There are different versions. … Twelve-point bolt with ribs is 70 Nm + 90° turn. … Twelve-point bolt without ribs is 200 Nm + 180° turn … Allways replace if removed … 10 - Bolt Refer to Brake System; Mechanical Components …...

  • Page 26: Driveshaft With Mounted Cv Joint Vl 107 Overview

    Driveshaft with mounted CV Joint VL 107 overview 1 - Bolt There are different versions. … Twelve-point bolt with ribs is 70 Nm + 90° turn. … Twelve-point bolt without ribs is 200 Nm + 180° turn … Allways replace if removed …...
  • Page 27 9 - CV Boot 10 - Clamp Allways replace if removed … 11 - Locking plate 12 - Cover 13 - Inner CV Joint 14 - Locking ring 15 - Cover Allways replace if removed … 16 - Internal multi-point Bolt 70 Nm …...

  • Page 28: Driveshaft With Cv Joint Vl107 Overview

    Driveshaft with CV joint VL107 overview 1 - outer CV Joint 2 - Bolt There are different versions. … Twelve-point bolt with ribs is 70 Nm + 90° turn. … Twelve-point bolt without ribs is 200 Nm + 180° turn …...
  • Page 29 10 - Clamp Allways replace if removed … 11 - CV Joint protective Boot 12 - Locking ring Allways replace if removed … 13 - Clamp Always replace if removed … 14 - CV Joint 15 - Cap VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 30: Driveshaft With Triple Roller Joint Aar3300I Overview

    Driveshaft with triple roller Joint AAr3300i overview 1 - outer CV Joint 2 - Bolt There are different versions. … Twelve-point bolt with ribs is 70 Nm + 90° turn. … Twelve-point bolt without ribs is 200 Nm + 180° turn …...
  • Page 31 10 - Clamp Allways replace if removed … 11 - CV Joint protective Boot 12 - Clamp Allways replace if removed … 13 - triple roller Star with rollers 14 - Locking ring Allways replace if removed … 15 - Joint 16 - Locking ring Allways replace if removed …...

  • Page 32: Driveshaft With Triple Roller Joint Aar3300I, 09M Automatic Transmission, 6-Speed, Awd Overview

    Driveshaft with triple roller Joint AAr3300i, 09m Automatic transmission, 6-Speed, AWD overview 1 - outer CV Joint 2 - Bolt There are different versions. … Twelve-point bolt with ribs is 70 Nm + 90° turn. … Twelve-point bolt without ribs is 200 Nm + 180° turn …...
  • Page 33 8 - Clamp Always replace if removed … 9 - CV Boot for triple roller Joint 10 - Clamp Allways replace if removed … 11 - triple roller Star with rollers 12 - Locking ring Allways replace if removed … 13 - Adapter 14 - Joint 15 - Cap...

  • Page 34: Rear Suspension

    Rear Suspension Subframe transverse Link and tie rods fWD overview 1 - Eccentric Bolt 2 - Eccentric Bolt 3 - Eccentric Washer 4 - nut 95 Nm … M12 x 1.5 … Always replace if removed … 5 - Eccentric Washer 6 - nut 95 Nm …...
  • Page 35 7 - Subframe 8 - Bolt 90 Nm + 90° turn … M12 x 1.5 x 95 … Always replace if removed … 9 - Lower transverse Link 10 - nut 90 Nm + 90° turn … M12 x 1.5 …...

  • Page 36: Left Rear Level Control System Sensor -G76- Fwd Overview

    Left rear Level Control System Sensor -G76- fWD overview 1 - Subframe 2 - Lower transverse Link 3 - Bolt 5 Nm … M5 x 20 … 4 - Left rear Level Control System Sensor VW Tiguan Quick Reference Specification Book • February 2014...
  • Page 37 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 38: Wheel Bearing Housing, Trailing Arm Fwd Overview

    Wheel Bearing Housing, trailing Arm fWD overview 1 - Cover 2 - Bracket 3 - Coupling rod 4 - Bolt 90 Nm + 90° turn … M12 x 1.5 x 40 … Always replace if removed … 5 - trailing Link 6 - Bolt 8 Nm …...
  • Page 39 11 - nut 40 Nm … Always replace if removed … 12 - Brake rotor 13 - Bolt 4 Nm … 14 - Dust Cap 15 - Bolt 200 Nm + 180° turn … M16 x 1.5 x 70 … Always replace if removed …...

  • Page 40: Shock Absorber, Coil Spring Fwd Overview

    Shock Absorber, Coil Spring fWD overview 1 - Low Spring Support 2 - Assembly Aid 3 - Coil Spring 4 - Upper Spring Support 5 - Bolt 180 Nm … M14 x 1.5 x 85 … Always replace if removed …...

  • Page 41: Stabilizer Bar Fwd Overview

    Stabilizer Bar fWD overview 1 - Stabilizer Bar 2 - rubber mount 3 - Clamp 4 - Bolt 25 Nm + 90° turn … M8 x 30 … Always replace if removed … 5 - Wheel Bearing Housing 6 - nut 40 Nm …...

  • Page 42: Subframe, Final Drive Awd Overview

    Subframe, final Drive AWD overview 1 - Subframe 2 - rear Bonded rubber Bushing 3 - front Bonded rubber Bushing 4 - final Drive 5 - Bolt 60 Nm + 90° turn … M12 x 105 … Always replace if removed …...

  • Page 43: Left Rear Level Control System Sensor -G76- Awd Overview

    Left rear Level Control System Sensor -G76- AWD overview 1 - Subframe 2 - Lower transverse Link 3 - Bolt 5 Nm … M5 x 20 … 4 - Left rear Level Control System Sensor -G76- VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 44: Transverse Link, Tie Rod Awd Overview

    transverse Link, tie rod AWD overview 1 - Eccentric Bolt 2 - nut 95 Nm … M12 x 1.5 … Always replace if removed … 3 - Eccentric Washer 4 - Eccentric Bolt 5 - Eccentric Washer 6 - nut 95 Nm …...
  • Page 45 10 - nut 90 Nm + 90° turn … Always replace if removed … 11 - Bolt M12 x 1.5 x 75 … Always replace if removed … 12 - threaded rivet … 13 - Expanding rivet 14 - Stone Chip protection 15 - Bolt 8 Nm …...

  • Page 46: Shock Absorber, Coil Spring Awd

    Shock Absorber, Coil Spring AWD 1 - Low Spring Support 2 - Assembly Aid 3 - Coil Spring 4 - Upper Spring Support 5 - Bolt 180 Nm … M14 x 1.5 x 70 … 6 - Bolt 50 Nm + 90° turn …...

  • Page 47: Stabilizer Bar Awd Overview

    Stabilizer Bar AWD overview 1 - Stabilizer Bar 2 - rubber mount 3 - Clamp 4 - Internal multi-point Bolt 25 Nm + 90° turn … M8 x 28 … Always replace if removed … 5 - Wheel Bearing Housing 6 - nut 40 Nm …...

  • Page 48: Driveshaft Overview

    Driveshaft overview 1 - outer CV Joint 2 - Boot Always replace if removed … 3 - Driveshaft 4 - Clamp Always replace if removed … 5 - protective Boot 6 - Clamp Always replace if removed … 7 - plate Spring 8 - Locking ring Always replace if removed …...
  • Page 49 12 - Internal multi-point Bolt 40 Nm … M8 x 48 … Always replace if removed … 13 - Gasket Always replace if removed … 14 - Wheel Bearing Housing 15 - Inner CV Joint 16 - plate Spring VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 50: Self-Leveling Suspension

    Self-Leveling Suspension Left and right front Level Control System Sensor -G78/G289-, Adaptive Chassis DCC overview 1 - Subframe 2 - Bolt 9 Nm … M6 x 16 … 3 - Left front Level Control System Sensor -G78- and right front Level Control Sensor -G289- 4 - Control Arm 5 - nut...

  • Page 51: Left Rear Level Control System Sensor -G76-, Adaptive Chassis Dcc, Fwd Overview

    Left rear Level Control System Sensor -G76-, Adaptive Chassis DCC, fWD overview 1 - Subframe 2 - Bolt 5 Nm … M5 x 20 … 3 - Left rear Level Control System Sensor -G76- 4 - Lower transverse Link VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 52: Left Rear Level Control System Sensor -G76-, Adaptive Chassis Dcc, Awd Overview

    Left rear Level Control System Sensor -G76-, Adaptive Chassis DCC, AWD overview 1 - Subframe 2 - Bolt 5 Nm … M5 x 20 … 3 - Left rear Level Control System Sensor -G76- 4 - Lower transverse Link VW Tiguan Quick Reference Specification Book • February 2014...
  • Page 53 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 54: Adaptive Chassis Dcc Suspension Strut Overview

    Adaptive Chassis DCC Suspension Strut overview 1 - Shock Absorber with Left front Dampening Adjustment Valve -n336- 2 - Stop Buffer 3 - protective Sleeve 4 - Coil Spring 5 - Wheel Bearing Housing 6 - Suspension Strut Bearing 7 - nut 60 Nm …...
  • Page 55 12 - Bolt 15 Nm + 90°additional turn … M8 x 26 … Always replace if removed … 13 - Bracket 14 - right front Body Acceleration Sensor -G342- 15 - nut 5 Nm … Always replace if removed … VW Tiguan Quick Reference Specification Book •...

  • Page 56: Adaptive Chassis Dcc Shock Absorber, Fwd Overview

    Adaptive Chassis DCC Shock Absorber, fWD overview 1 - Lower Spring Support 2 - Coil Spring 3 - Upper Spring Support 4 - Bracket 5 - rear Body Acceleration Sensor -G343- 6 - Bolt 5 Nm … Always replace if removed …...
  • Page 57 9 - Shock Absorber with Left and right rear Dampening Adjustment Valve -n338/n339- 10 - Washer 11 - Lower transverse Link 12 - Wheel Bearing Housing VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 58: Adaptive Chassis Dcc Shock Absorber, Awd Overview

    Adaptive Chassis DCC Shock Absorber, AWD overview 1 - Lower Spring Support 2 - Coil Spring 3 - Upper Spring Support 4 - Bracket 5 - rear Body Acceleration Sensor -G343- 6 - Bolt 5 Nm … Always replace if removed …...
  • Page 59 8 - Bolt 50 Nm + 90° turn … M10 x 35 … Always replace if removed … 9 - Shock Absorber 10 - Washer 11 - Lower transverse Link 12 - Wheel Bearing Housing VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 60: Wheels, Tires, Wheel Alignment

    Wheels, Tires, Wheel Alignment tire pressure And metal Valve Sensor overview 1 - Valve Cap 2 - nut 3 - Washer 4 - Disk Wheel 5 - Seal 6 - Valve Core 7 - metal Valve 8 - Bolt 4 Nm …...

  • Page 61: Fastener Tightening Specifications

    Fastener Tightening Specifications Component Control arm mounting bracket-to-body mounting bolt 70 plus an additional 180° (½ turn) Front mounting bracket-to-body bolt 70 plus an additional 180° (½ turn) Front subframe-to-body mounting bolt 70 plus an additional 180° (½ turn) Tie rod end-to-tie rod lock nut Tire pressure sensor to metal valve bolt, with autolocation Tire pressure sensor union nut...
  • Page 62 Wheel Alignment Specified Values (cont’d) front suspension Basic suspension Basic suspension with adaptive US version chassis DCC PR numbers Total toe (wheels not pressed) 10’ ± 10′ 10’ ± 10′ Camber (wheels in straight -27′ ± 30′ -27′ ± 30′ ahead position) Maximum permissible difference 30’...

  • Page 63: Steering

    Steering Steering Column overview 1 - Steering Column Crossmember 2 - Steering Column 3 - Bolt 20 Nm … 4 - Brake pedal Crash Brace 5 - Clutch pedal Crash Brace 6 - Bolt 30 Nm … Always replace if removed …...

  • Page 64: Electro-Mechanical Steering Gear Overview

    Electro-mechanical Steering Gear overview 1 - Universal Joint 2 - Bolt 30 Nm … M8 x 35 … Always replace if removed … 3 - power Steering Gear 4 - Wheel Bearing Housing 5 - nut 50 Nm … M12 x 1.5 …...

  • Page 65: Fastener Tightening Specifications

    8 - Heat Shield 9 - torx® Bolt 6 Nm … 10 - Electrical Wire Fastener Tightening Specifications Component fastener size Ball joint-to-control arm nut - To aluminum control arm - To steel control arm Mounting bracket-to-body bolt 70 plus an additional 90°...

  • Page 66: Brake System

    BrAkE SyStEm General, Technical Data Vehicle Data Sticker pr number Allocation The Production Relevant No. (PR. No.) on the vehicle data label describes which brake system is installed in the vehicle. Example: (Æ) - Front brakes - 1LJ The vehicle data label can be found in the spare wheel well and the maintenance booklet.

  • Page 67: Front Brakes

    The following tables explain the PR numbers. This is important in order to know the brake caliper/ brake disc and brake pad combination. front Brakes Engine Version pr number front Wheel Brake 2.0L - 147 kW FSI FN 3 (16”) rear Brakes Engine Version pr number...

  • Page 68: Front Brakes, Fn 3

    front Brakes, fn 3 Item pr number 1LJ / 1ZD Brake caliper FN 3 (16”) Brake pad thickness Brake disc Diameter in Brake disc thickness Brake caliper piston Diameter in VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 69: Rear Brakes, Cii 41

    rear Brakes, CII 41 Item pr number Brake caliper CII 41 (16”) Brake pad thickness Brake disc Diameter in Brake disc thickness Brake caliper piston Diameter in VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 70: Anti-Lock Brake System (Abs)

    Anti-lock Brake System (ABS) Control module and Hydraulic Unit overview 1 - Brake Booster 2 - Brake Line 3 - Brake Line 4 - Brake Line 5 - Brake Line 6 - Brake Line 7 - Brake Line 8 - ABS Control module -J104- 9 - ABS Hydraulic Unit -n55- 10 - Electrical Wire 11 - torx®...

  • Page 71: Front Axle Abs Components Overview

    front Axle ABS Components overview 1 - Wheel Speed Sensor Before inserting the speed sensor, clean the inner surface of the … hole and coat it with hot bolt paste G 052 112 A3. 2 - Hex Socket Bolt 8 Nm …...

  • Page 72: Rear Axle Abs Components, Fwd Overview

    rear Axle ABS Components, fWD overview 1 - Wheel Speed Sensor Before inserting the speed sensor, clean the inner surface of the … hole and coat it with hot bolt paste G 052 112 A3. 2 - Hex Socket Bolt 8 Nm …...

  • Page 73: Rear Axle Abs Components, Awd

    rear Axle ABS Components, AWD 1 - Wheel Speed Sensor Before inserting the speed sensor, clean the inner surface of the … hole and coat it with hot bolt paste G 052 112 A3. 2 - Hex Socket Bolt 8 Nm …...

  • Page 74: Mechanical Components

    Mechanical Components front Wheel Brakes fn 3 Assembly overview 1 - torx® Bolt 12 Nm … 2 - Brake Disc 3 - torx® Bolt 4 Nm … 4 - Brake pads 5 - retaining Spring 6 - Brake Carrier 7 - Brake Caliper 8 - Guide pins 30 Nm …...
  • Page 75 11 - Universal Joint 12 - Guide pins 30 Nm … 13 - Bolt 14 - Bracket 15 - ribbed Bolt 200 Nm … M12 x 1.5 … Always replace if removed … 16 - Wheel Bearing Housing 17 - Wheel Speed Sensor 18 - Hex Socket Bolt 8 Nm …...

  • Page 76: Rear Brakes Cii 41 Assembly Overview

    rear Brakes CII 41 Assembly overview 1 - Cover plate 2 - Brake Disc 3 - Inner torx® Bolt 4 Nm … 4 - multi-point Socket Head Bolt 90 Nm + 90° turn … Always replace if removed … 5 - Brake Carrier with Guide pins and protective Cap 6 - Anti-rattle Spring 7 - Brake pads 8 - Heat Shield...
  • Page 77 12 - Seal 13 - parking Brake motor 14 - Inner torx® Bolt 12 Nm … 15 - Bracket 16 - Brake Hose with Banjo fitting and Union Bolt 35 Nm … To the brake caliper … To the brake line, 14 Nm …...

  • Page 78: Brake Pedal Assembly Overview

    Brake pedal Assembly overview 1 - mounting Bracket 2 - Self-Locking Hex nut 25 Nm … Always replace if removed … 3 - noise Insulation on the Brake pedal 4 - Clamping Washer 5 - Brake pedal 6 - Self-Locking Hex nut 25 Nm …...

  • Page 79: Hydraulic Components

    Hydraulic Components front Brake Caliper, fn 3 overview 1 - Dust Cap 2 - Bleeder Valve 10 Nm … Apply a thin coat of assembly paste G 052 150 A2 to the threads … before screwing in. 3 - Caps 4 - Guide pins 30 Nm …...

  • Page 80: Rear Brake Caliper, Cii 41 Overview

    rear Brake Caliper, CII 41 overview 1 - Brake Caliper 2 - Hex Bolt, Self-Locking 35 Nm … Always replace if removed … 3 - Dust Cap 4 - Bleeder Valve 10 Nm … Apply a thin coat of assembly paste G 052 150 A2 to the threads …...
  • Page 81 11 - protective Cap 12 - pistons 13 - Seal 14 - pressire nut VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 82: Brake Booster/Brake Master Cylinder Overview

    Brake Booster/Brake master Cylinder overview 1 - pedal Assembly 2 - Self-Locking Hex nut 25 Nm … Always replace if removed … First tighten at the lower left and then the upper right … 3 - Gasket 4 - Brake Booster 5 - Seal 6 - Brake master Cylinder 7 - Inner torx®...
  • Page 83 11 - Brake Line 14 Nm … 12 - Brake Line 14 Nm … 13 - Sealing plugs 14 - Brake fluid reservoir 15 - Cap 16 - Vacuum Hose 17 - Sealing plugs VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 84: Body

    BoDy Body Exterior Body Gap Dimensions, front Component 7.5 ± 1.0 5.5 ± 1.0 5.5 ± 1.0 5.0 ± 1.0 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 85: Body Gap Dimensions, Center

    Body Gap Dimensions, Center Component 4.0 ± 1.0 4.5 ± 1.0 4.0 ± 1.0 4.5 ± 1.0 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 86: Body Gap Dimensions, Rear

    Body Gap Dimensions, rear Component 3.0 ± 1.0 6.0 ± 0.5 3.5 ± 0.5 6.0 ± 1.0 5.0 ± 1.0 1.0 ± 1.0 VW Tiguan Quick Reference Specification Book • February 2014...
  • Page 87 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 88: Body Front

    Body front Lock Carrier Assembly overview 1 - Lock Carrier with Attachments 2 - Bolt 2 Nm … 3 - Air Duct 4 - Bolt 8 Nm … 5 - Bolt 8 Nm … 6 - Left Side Angle Bracket 7 - Driver front Airbag Crash Sensor 8 - Bolt 6 Nm...
  • Page 89 10 - Left Air Vent 11 - Lower Air Vent 12 - right Air Vent 13 - Bolt 8 Nm … 14 - Lock Support 15 - Lock 16 - Left Side Angle Bracket 17 - Bolt 12 Nm … VW Tiguan Quick Reference Specification Book •...

  • Page 90: Bumper Angle Brackets Assembly Overview

    Bumper Angle Brackets Assembly overview 1 - Angle Bracket 2 - Bolt 55 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 91: Front Fender Assembly Overview

    front fender Assembly overview 1 - fender 2 - foam piece 3 - Bolt 7.5 Nm … 4 - Spacer 5 - Bolt 7.5 Nm … 6 - fender End plate 7 - Bolt 7.5 Nm … 8 - fender Brace 9 - Bolt 7.5 Nm …...

  • Page 92: Noise Insulation, Long Version, Assembly Overview

    noise Insulation, Long Version, Assembly overview 1 - noise Insulation 2 - Bolt 2 Nm … 3 - Bolt 2 Nm … 4 - Bolt 6 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 93: Noise Insulation, Short Version, Assembly Overview

    noise Insulation, Short Version, Assembly overview 1 - noise Insulation 2 - Bolt 2 Nm … 3 - Bolt 2 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 94: Underbody Impact Guard

    Underbody Impact Guard 1 - Underbody Impact Guard 2 - Bolt 20 Nm … 3 - Bolt 2 Nm … 4 - Bolt 20 Nm … 5 - Bolt 35 Nm … 6 - Cross Brace 7 - Expanding nut VW Tiguan Quick Reference Specification Book •...

  • Page 95: Underbody Trim Assembly Overview

    Underbody trim Assembly overview 1 - Underbody trim 2 - nut 2 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 96: Bulkhead Assembly Overview

    Bulkhead Assembly overview 1 - Bulkhead 2 - Bolt 25 Nm … 3 - pUr Adhesive Sealant VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 97: Hood, Lids

    Hood, Lids Hood release Assembly overview 1 - mounting Bracket 2 - Actuating Lever 3 - Clip 4 - Bolt 1.5 Nm … 5 - release Cable 6 - Bracket 7 - Insert nut VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 98: Rear Lid Locking And Unlocking Components Assembly Overview

    rear Lid Locking and Unlocking Components Assembly overview 1 - rear Lid Latch 2 - Bolt 23 Nm … 3 - Grip with Button Screw tightening torque: 2 Nm … 4 - Connectors 5 - Button 6 - nut 4 Nm …...

  • Page 99: Gas-Filled Strut Assembly Overview

    Gas-filled Strut Assembly overview 1 - Gas Strut 2 - Angle Bracket 3 - Screws 8 Nm … 4 - Ball Head pin 8 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 100: Fuel Filler Door Unit And Actuator Assembly Overview

    fuel filler Door Unit and Actuator Assembly overview 1 - fuel filler Door Unit 2 - Bolt 1.5 Nm … 3 - Water Drain Hose 4 - Actuator 5 - Seal 6 - Connector VW Tiguan Quick Reference Specification Book • February 2014...
  • Page 101 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 102: Front Doors, Central Locking System

    front Doors, Central Locking System front Door Assembly overview 1 - Door 2 - Door Handle 3 - Backing 4 - Cover 5 - Lock Cylinder 6 - Door Lock 7 - Subframe 8 - Bolt 32 Nm … Always replace bolts after loosening them …...
  • Page 103 11 - Bolt 32 Nm … Always replace bolts after loosening them … 12 - Bolt 9 Nm … 13 - Limiting Strap 14 - Bolt 32 Nm … 15 - Upper Door Hinge VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 104: Door Hinge Assembly Overview

    Door Hinge Assembly overview 1 - Door 2 - Door Hinge 3 - Bolt 32 Nm … Always replace bolts after loosening them … 4 - Bolt 30 Nm … 5 - Door Hinge 6 - Bolt 32 Nm … Always replace bolts after loosening them …...
  • Page 105 10 - Bolt 32 Nm … 11 - Bolt 32 Nm … Always replace bolts after loosening them … 12 - Door Hinge 13 - Bolt 30 Nm … 14 - Door Hinge 15 - Bolt 32 Nm … Always replace bolts after loosening them …...

  • Page 106: Subframe Assembly Overview

    Subframe Assembly overview 1 - Door 2 - release Cable 3 - Cover Caps for Assembly opening 4 - Subframe 5 - Door Lock 6 - Bolt 20 Nm … 7 - Bolt 8 Nm … 8 - Wiring Harness 9 - Window regulator motor 10 - Window regulator 11 - Bolt...

  • Page 107: Door Limiting Strap Assembly Overview

    Door Limiting Strap Assembly overview 1 - Door Limiting Strap 2 - Cover 3 - Bolt 9 Nm … 4 - Bolt 32 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 108: Door Handle And Door Lock Assembly Overview

    Door Handle and Door Lock Assembly overview 1 - Door Lock 2 - Bolt 20 Nm … 3 - Cable 4 - Backing 5 - Lock Cylinder 6 - Cover 7 - Door Handle 8 - Cable 9 - Bolt 4.5 Nm …...
  • Page 109 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 110: Rear Doors

    rear Doors rear Door Assembly overview 1 - Door 2 - Door Handle with Backing plate 3 - Cover 4 - Subframe with Door Lock 5 - Bolt 30 Nm … 6 - Door Hinge 7 - Bolt 32 Nm …...
  • Page 111 10 - Bolt 9 Nm … 11 - Bolt 32 Nm … Always replace bolts after removing them. … 12 - Door Hinge 13 - Bolt 30 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 112: Door Hinge Assembly Overview

    Door Hinge Assembly overview 1 - Door 2 - Door Hinge 3 - Bolt 32 Nm … Always replace bolts after loosening them … 4 - Bolt 30 Nm … 5 - Door Hinge 6 - Bolt 32 Nm … Always replace bolts after loosening them …...
  • Page 113 10 - Bolt 9 Nm … 11 - Bolt 32 Nm … Always replace bolts after loosening them … 12 - Door Hinge 13 - Bolt 30 Nm … 14 - Door Hinge 15 - Bolt 32 Nm … Always replace bolts after loosening them …...

  • Page 114: Subframe Assembly Overview

    Subframe Assembly overview 1 - Subframe 2 - release Cable 3 - Door Lock 4 - Bolt 20 Nm … 5 - Bolt 8 Nm … 6 - Cover Caps for Assembly opening 7 - Window regulator motor 8 - Connectors 9 - Window regulator VW Tiguan Quick Reference Specification Book •...

  • Page 115: Door Handle And Door Lock Assembly Overview

    Door Handle and Door Lock Assembly overview 1 - Door Lock 2 - Bolt 20 Nm … 3 - Cable 4 - Cable 5 - mounting Bracket 6 - Bolt 7 - Door Handle with Backing plate 8 - Cover 9 - Backing 10 - Angle Bracket VW Tiguan Quick Reference Specification Book •...

  • Page 116: Sunroof

    Sunroof panorama Sunroof Assembly overview 1 - Sun Shade rail 2 - Guide rail 3 - Bolt 2 Nm … 4 - rear Lid part 5 - rear motor Support 6 - front motor Support 7 - front part 8 - Inner Seal VW Tiguan Quick Reference Specification Book •...

  • Page 117: Assembly Frame Overview

    Assembly frame overview 1 - Assembly frame 2 - Bolts See illustration below … 3 - Screw 8 Nm … 4 - Screw 4.5 Nm … 5 - Console 6 - Centering Hole 7 - Centering Hole 8 - Sunroof motor VW Tiguan Quick Reference Specification Book •...
  • Page 118 Assembly frame overview (cont’d) 1 - Assembly frame 2 - Screws Tighten first the screws identified with letters -2- in alphabetical … order to 8 Nm. Tighten the remaining screws -2- on the assembly frame -1- to 8 … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 119: Sunroof Tightening Specifications

    Sunroof Tightening Specifications Component Cable cover screws Glass panel screws Sunroof motor screws Shade motor screws Rear part guide rail screws Wind deflector screws VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 120: Bumpers

    Bumpers front Bumper Cover Assembly overview 1 - front Bumper Cover 2 - Bolt 2 Nm … 3 - Bolt 2 Nm … 4 - Wheel Cover 5 - Bracket 6 - Bolt 2 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 121: Front Bumper Carrier Assembly Overview

    front Bumper Carrier Assembly overview 1 - front Bumper Carrier 2 - Bolt 8 Nm … 3 - Bolt 60 Nm … 4 - Angle Bracket 5 - Bolt 8 Nm … 6 - Cross member 7 - Angle Bracket 8 -Bolt 8 Nm …...

  • Page 122: Rear Bumper Cover Assembly Overview

    rear Bumper Cover Assembly overview 1 - rear Bumper Cover 2 - Bolt 3.5 Nm … 3 - Guide trim 4 - Wheel Cover 5 - Expanding rivet 6 - Catches 7 - Bolt 2 Nm … 8 - Bolt 6 Nm …...

  • Page 123: Rear Bumper Cover Substructure

    rear Bumper Cover Substructure 1 - Guide trim 2 - Screws 3.5 Nm … 3 - Expanding nut 8 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 124: Rear Bumper Carrier Assembly Overview

    rear Bumper Carrier Assembly overview 1 - rear Bumper Carrier 2 - Bolt 20 Nm … 3 - right foam piece 4 - Left foam piece VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 125: Trailer Hitch Assembly Overview

    trailer Hitch Assembly overview 1 - trailer Hitch 2 - Bolt 50 Nm + 90° turn … Replace after loosening … 3 - Bolt 20 Nm … 4 - Connectors 5 - Bolt 80 Nm … 6 - foam piece VW Tiguan Quick Reference Specification Book •...

  • Page 126: Glass, Window Regulators

    Glass, Window regulators front Door Window Assembly overview 1 - Door Window 2 - Decorative trim Strip 3 - Clip 4 - Window Guide 5 - trim 6 - Bolt 2 Nm … 7 - Spring nut 8 - outer Window Shaft Seal 9 - Inner Window recess Seal 10 - Bolt 20 Nm...
  • Page 127 12 - Cover 13 - Bolt 8 Nm … 14 - Window regulator motor 15 - Connector 16 - Subframe 17 - Window regulator VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 128: Rear Door Window Assembly Overview

    rear Door Window Assembly overview 1 - Door Window 2 - Adhesive tape 3 - Spring nut 4 - Clip 5 - trim 6 - Bolt 2 Nm … 7 - Decorative trim Strip 8 - Window Guide 9 - outer Window recess Seal 10 - Centering pin 11 - fixed Door Window 12 - Bolt...
  • Page 129 15 - Cover 16 - Clamping Brackets 17 - Spreader pin 18 - Spreader plug 19 - Cover 20 - Subframe 21 - rivet 22 - Window regulator motor 23 - Connector 24 - Window regulator 25 - Coverr VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 130: Exterior Equipment

    Exterior Equipment front Wheel Housing Liner Assembly overview 1 - Wheel Housing Liner 2 - Expanding nut 3 - Bolt 2 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 131: Rear Wheel Housing Liner Assembly Overview

    rear Wheel Housing Liner Assembly overview 1 - Wheel Housing Liner 2 - Expanding nut 3 - Insert nut 4 - rear Sill panel Cover 5 - Bolt 2 Nm … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 132: Exterior Rearview Mirror Assembly Overview

    Exterior rearview mirror Assembly overview 1 - mirror Base plate 2 - mirror Housing 3 - Housing frame 4 - Bolt 1 Nm … 5 - Assembly piece 6 - mirror Glass 7 - Insulation VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 133: Roof Rail Assembly Overview

    roof rail Assembly overview 1 - mirror Base plate 2 - mirror Housing 3 - Housing frame 4 - Bolt 1 Nm … 5 - Assembly piece 6 - mirror Glass 7 - Insulation VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 134: Front And Rear Door Cover Assembly Overview

    front and rear Door Cover Assembly overview 1 - front Door Cover 2 - front Door 3 - rear Door 4 - Grommet 5 - rear Door Cover 6 - Adhesive tape 7 - Bolt 2 Nm … 8 - Bolt 2 Nm …...

  • Page 135: Body Interior

    Body Interior Interior Equipment Tightening Specifications Component Center console to mount screws Center console mounting bracket nuts to floor Driver side left trim panel screws Foot cover screws Glove compartment screws Headliner console bolts Heater and A/C control trim screws Lower instrument panel trim screws Lower rear center console screws to mount Rear wheel housing trim (with rear side airbag)

  • Page 136: Passenger Protection, Airbags, Seat Belts

    passenger protection, Airbags, Seat Belts front Bumper Cover Assembly overview 1 - Console 2 - Automatic Belt retractor 3 - Hex nut 40 Nm … 4 - Bolt 40 Nm … 5 - Belt Anchor VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 137: Tightening Specifications

    Tightening Specifications Component Airbag control module bracket nuts to body Airbag control module nuts to body Driver and passenger front airbag crash sensor bolt Driver and passenger seat side airbag bolt to seat frame Outer rear seat belt automatic belt retractors bolt to mount Passenger airbag unit bolts to instrument panel Rear seat belt latch seat frame...

  • Page 138: Seat Frames

    Seat frames Tightening Specifications Component Backrest folding table scews Backrest to seat bolts 34.5 Door sill side trim bracket bolts Door sill side trim screws Height adjustment drive bolt Height adjustment element bolts 6 ± 2 Height adjustment lever to seat bolt 19.5 Lumbar adjustment switch screws Lower door sill side trim bracket bolt...

  • Page 139: Heating, Ventilation & Air Conditioning

    HEAtInG, VEntILAtIon & AIr ConDItIonInG General, Technical Data refrigerant oil Distribution Component Approximate % of total amount of oil in component A/C compressor Condenser Suction hose Evaporator Fluid reservoir VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 140: Refrigerant R134A Vapor Pressure Table

    refrigerant r134a Vapor pressure table temperature in °C pressure in bar (positive pressure) of r134a -0.61 -0.49 -0.34 -0.16 0.06 0.32 0.63 1.00 1.43 1.92 2.49 3.13 3.90 4.70 5.63 6.70 7.83 9.10 10.54 12.11 13.83 15.72 17.79 20.05 22.52 25.21 28.14 31.34...

  • Page 141: Heating, Ventilation

    Heating, Ventilation Fastener Tightening Specifications Component Air distribution housing bolts Air grille 2.5 ± 0.4 Auxiliary heater heating element connector nut 9 ± 1 Footwell vents 1.5 ± 0.2 Fresh air blower bolts Heater control bolts 1.5 ± 0.2 Heater core connection flange bolt Heater core pipe clamps Heater unit screws 4.5 ±...

  • Page 142: Air Conditioning

    Air Conditioning Fastener Tightening Specifications Component A/C compressor bolts Air distribution door motor Condenser-to-radiator 5 ± 0.5 Defroster door motor Evacuating and charging valve insert 2.4 ± 0.2 Expansion valve Expansion valve heat shield Fluid reservoir with dryer 4.2 ± 0.7 Fluid reservoir with dryer clamp bolt Fresh air/recirculating air/back pressure door motor Front air distribution door motor...
  • Page 143 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 144: Electrical System

    ELECtrICAL SyStEm Electrical Equipment Battery, Starter, Generator, Cruise Control Battery overview 1 - Battery terminal Clamp Ground Wire 2 - mounting nut for Battery terminal Clamp Ground Wire 6 Nm … … 3 - Battery terminal Clamp positive Wire 4 - mounting nut for Battery terminal Clamp positive Wire 6 Nm …...
  • Page 145 6 - Clamping plate 7 - Bolt 20 Nm … M8 x 35 … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 146: Generator Overview

    Generator overview 1 - Collar Bolt 20 Nm … M8 x 110 … 2 - phillips Head Screws 2 Nm … M4 x 19 … 3 - Washer … 4 - phillips Head Screws 4.5 Nm … M5 x 21 …...
  • Page 147 8 - phillips Head Screws 2 Nm … M4 x 13 … 9 - Voltage regulator 10 - Generator 11 - ribbed Belt VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 148: Starter Overview

    Starter overview 1 - Starter 2 - Connection B+ Wire to Starter 3 - mounting nut B+ Wire to Starter 4 - Starter Bolts 75 Nm … … 5 - Cap 6 - mounting nuts, Wiring Bracket 15 Nm … …...

  • Page 149: Windshield Wiper/Washer System

    Windshield Wiper/Washer System rear Window Wiper System overview 1 - Cap 2 - nut 12 Nm … 3 - Wiper Arm 4 - Gasket 5 - Joint-free Wiper Blade 6 - Spray nozzle 7 - rear Window Wiper motor -V12- 8 - m6 nut With Washer 8 Nm …...

  • Page 150: Windshield Wiper System Overview

    Windshield Wiper System overview 1 - mounting nuts, Wiper Arm to Linkage 20 Nm … 2 - Joint-free Windshield Wiper 3 - Wiper Arms 4 - Bolts for Wiper frame With Linkage to Body 8 Nm … 5 - Wiper frame With Linkage 6 - Windshield Wiper motor -V- with Wiper motor Control module -J400- 7 - rubber Grommet In the Bulkhead...

  • Page 151: Windshield Wiper/Washer System Tightening Specifications

    Windshield Wiper/Washer System Tightening Specifications Component fastener size Washer fluid reservoir-to-body VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 152: Exterior Lights, Switches

    Exterior Lights, Switches fog Lamps overview 1 - front Bumper Cover 2 - fog Lamp Housing 3 - Bolt 1.5 Nm … 4 - Left fog Lamp Bulb -L22- or right fog Lamp Bulb -L23- And Left Cornering Lamp Bulb -L148- And right Cornering Lamp Bulb -L149- 5 - Vent Hose 6 - Divider VW Tiguan Quick Reference Specification Book •...
  • Page 153 VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 154: Halogen Headlamps Overview

    Halogen Headlamps overview 1 - Headlamp 2 - mounting Screws, Headlamp to Body 4 Nm … 6 x 40 … 3 - Left Low Beam Headlamp -m29- and right Low Beam Headlamp -m31- 4 - Lamp Socket With Grip 5 - Cap 6 - Headlamp Beam Adjustment motor 7 - Cap 8 - Left parking Lamp -m1- and right parking Lamp -m3-...
  • Page 155 12 - Left front turn Signal Lamp -m5- and right front turn Signal Lamp -m7- 13 - Carrier 14 - Bolts: Headlamp to Carrier 4 Nm … 6 x 40 … VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 156: Hid Headlamp And Cornering Lamp Overview

    HID Headlamp and Cornering Lamp overview 1 - Headlamp 2 - Left HID Headlamp Bulb -L13- and right HID Headlamp Bulb -L14- 3 - Cap 4 - Left Cornering Lamp -L148- or right Cornering Lamp -L149- 5 - Left front turn Signal Light -m5- and right front turn Signal Light -m7- 6 - Cap 7 - mounting Screws, Headlamp to Body...
  • Page 157 12 - Screws Connect the Headlamp power output Stage to the Headlamp 13 - Carrier 14 - Bolts: Headlamp to Carrier 4 Nm … 6 x 14 … 15 - Left Headlamp power output Stage -J667- or right Headlamp power output Stage -J668- 16 - Left LED parking Lamp/DrL module -L176- and right LED parking Lamp/DrL module -L177- VW Tiguan Quick Reference Specification Book •...

  • Page 158: Rear Lid Tail Lamps Overview

    rear Lid tail Lamps overview 1 - nut 3 Nm … 2 - Bolb Holder 3 - right tail Lamp -m2- and Left tail Lamp -m4- 4 - Left rear fog Light -L46- and right rear fog Light -L47- Not applicable to USA or Canada. …...

  • Page 159: Rear View Camera System Overview

    rear View Camera System overview 1 - radio/navigation Display Control module -J503- 2 - rear View Camera System Control module -J772- 3 - rear View Camera -r189- Nuts: 6 Nm … 4 - Steering Angle Sensor -G85- VW Tiguan Quick Reference Specification Book • February 2014...

  • Page 160: Steering Column Switch, Without Kessy, Overview

    Steering Column Switch, Without kESSy, overview 1 - Steering Column Electronic Systems Control module -J527- 1.5 Nm … 2 - Steering Column Combination Switch -E595- 3 - Steering Column Switch mount 4 - Shear Bolts 15 Nm … M8 x 20 …...

  • Page 161: Steering Column Switch, With Kessy, Overview

    Steering Column Switch, With kESSy, overview 1 - Steering Column Electronic Systems Control module -J527- 1.5 Nm … 2 - Steering Column Combination Switch -E595- 3 - Steering Column Switch mount 4 - Shear Bolts 15 Nm … M8 x 20 …...

  • Page 162: Tail Lamps In Side Panel Overview

    tail Lamps in Side panel overview 1 - Side Latch 2 - Bulb Holder 1.5 Nm … 3 - Left Brake/tail Light -m21- and right Brake/tail Light -m22- 4 - Left rear turn Signal Lamp -m6- and right rear turn Signal Lamp -m8- 5 - Divider 6 - Screws...

  • Page 163: Interior Lights, Switches Tightening Specification

    Interior Lights, Switches Tightening Specification Component Horns Wiring Tightening Specifications Component fastener size Engine compartment E-box Engine compartment E-box central bolt Instrument panel fuse panel Towing recognition control module bolt VW Tiguan Quick Reference Specification Book • February 2014...

Table of Contents

Save PDF
