Permobil F5 Corpus User Manual page 121

F5 Corpus
Seat-to-floor function
The seat can be lowered to the floor by pressing the upper part of
the button, and raised by pressing the lower part.
Power footplates
The footplates can be raised by pressing the lower part of the button
and lowered by pressing the upper part.
Power transfer footplate
The footplate can be lowered at the same time as the seat lift is raised
by pressing the upper part of the button. Pressing the lower part of
the button will raise the footplate and at the same time lower the seat
lift. This function can help the user get in and out of the wheelchair.
Getting to know your wheelchair
Figure 96. Seat to floor function.
Figure 97. Power footplates.
Figure 98. Power transfer footplate.
121
