Ascom Myco Wi-Fi and Cellular Smartphone
Priority color Priority
Red
Yellow
Cyan
7.3.2

Category color

IMPORTANT: There is no priority handling for category colors, they are used for information
Categories can be used to label alerts with a color, for example to differentiate between
alerts coming from different rooms or patient groups.
Figure 22. Alerts labeled with category colors.
The following category colors are available:
• Red
• Green
• Blue
• Yellow
• Orange
• Cyan
• Purple
NOTE: The category colors are dependant on configuration, and can differ between system
setups. Contact your site administrator for details about the use of category colors at
your site.
7.3.3

Alert type icons

The alert type icons indicate the alert type, for example a patient call, or a lab result
notification.
26 April 2016 / Ver. D
7. Alerts
Used for event
Crisis/ "Code Blue" crisis alert/
High High priority alert
Medium Medium priority alert
Low Low priority alert
only. Alerts from patient monitoring systems will always use their priority
color, and cannot be labeled with a category color.
Indications (if enabled)
Top display notification, red flashing
LED priority beacon, sound, and
vibrator.
IMPORTANT: These indications are
always enabled, and cannot be turned
off
Top display notification, yellow
flashing LED priority beacon, sound,
and vibrator.
Top display notification, fixed cyan LED
priority beacon, sound, and vibrator.
