User Manual
Ascom Myco Wi-Fi and Cellular Smartphone
• Long press mode
- Press and hold the button for longer than a second.
• Multi-press mode
- Press the button multiple times under a short period of time.
The functionality for these two input modes is set by the system administrator.
3.1.6

Top display

The top display is used to quickly get information about incoming calls, messages or alerts,
without having to use the main display.
• Refer to
display.
• Refer to
are shown in the top display.
3.1.7

Color pad for clip

Used to differentiate the handsets between, for example, workgroups, shifts, or roles. The
blue color pad is attached by default, and it can be exchanged by one of the colors, red,
yellow, or green. See
3.2

Accessories

The following accessories are available for the handset:
Battery Pack
Spare clip
Safety cord
Color pad kit for clip
CR5 Charging Rack
CR6 Battery Charging Rack The Battery Charging Rack(CR6) charges up to six spare
Table adapters for
Charging Rack (CR5/CR6)
Micro USB cable
USB Power supply
26 April 2016 / Ver. D
3. Handset Description
7.2.1 Top display on page 42 for details on how alerts are shown in the top
10.2 Color-coded LED Signals
17.3 Replace the Color Pad for the Hinge-type Clip
A replacement Battery Pack may be replaced and charged
separately in the battery pack charger.
The replacement hinge-type clip is especially designed to fit
one-layered fabric, like shirt pockets.
The Safety Cord is attached around the clip to prevent from
dropping the handset.
The color pad can be attached to the clip, and is used to easily
identify the handset belonging to, for example, a workgroup,
shift, or role.
The Charging Rack (CR5) charges up to six handsets at the
same time.
batteries at the same time.
With the attachable feet the charging racks can be placed
standing on a table.
Can be used to charge one handset at a time, for example at
own desk. Used with the USB Power supply.
The USB Power supply is used with the Micro USB cable.
on page 53 for details on how other notifications
TD 93066EN
on page 69.
9
