Advantech UNO-2271G V3 User Manual

Advantech UNO-2271G V3 User Manual

Intel pocket-size gateway with intel atom x7211re
Hide thumbs Also See for UNO-2271G V3:

Advertisement

Quick Links

Download this manual
User Manual
UNO-2271G V3 電腦
®
Intel
Pocket-Size Gateway with
Intel® Atom x7211RE

Advertisement

loading
Need help?

Need help?

Do you have a question about the UNO-2271G V3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech UNO-2271G V3

Summary of Contents for Advantech UNO-2271G V3

  • Page 1 User Manual UNO-2271G V3 電腦 ® Intel Pocket-Size Gateway with Intel® Atom x7211RE...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.

  • Page 3: Product Warranty (2 Years)

    Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.

  • Page 4: Declaration Of Conformity

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Please contact your local supplier for ordering information.

  • Page 5: Safety Instructions

    This equipment is not suitable for use in locations where children are likely to be present. If the equipment is used in a manner not specified by the Advantech, the protec- tion provided by the equipment may be impaired. UNO-2271G V3 User Manual...

  • Page 6: Consignes De Sécurité

    Advantech for further information. Caution: Hot surface. Do not touch for Top Heatsink. DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. Consignes de sécurité...
  • Page 7 Attention: Surface chaude, ne pas toucher pour le dissipateur thermique supérieur. ATTENTION: Danger d'explosion si la batterie est mal remplace. Remplacer unique- ment par le meme type ou equivalent recommandé par le fabricant. Jeter les piles usagées selon les instructions du fabricant. UNO-2271G V3 User Manual...
  • Page 8 請注意設備上所有的警告標示。 如果長時間不使用設備，請拔除與電源插座的連結，避免設備被超標的電壓波動 損壞。 請勿讓任何液體流入通風口，以免引起火灾或短路。 請勿自行打開設備。為了確保您的安全，請透過經認證的工程師來打開設備。 如遇下列情况，請由專業人員維修： 電源線或插頭損壞； 設備內部有液體流入； 設備曾暴露在過度潮濕環境中使用； 設備無法正常工作，或您無法透過用戶手冊來正常工作； 設備摔落或損壞； 設備有明顯外觀損； 請勿將設備儲存在超出建議溫度範圍的環境，即不要低於 -40°C（-40°F）或 高於 85°C（185°F），否則可能會造成設備損壞。 注意：若電池更換不正確，將有爆炸危險。因此，只可以使用製造商推薦的同一 種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。 根據 IEC 704‐1:1982 規定，操作員所在位置音量不可高於 70 分貝。 限制區域：請勿將設備安裝於限制區域使用。 免責聲明：請安全訓示符合 IEC 704‐1 要求。研華公司對其內容之準確性不承 擔任何法律責任。 消费者若使用电源适配器供电，则应购买配套使用获得 CCC 认证并满足标准要 求的电源适配器。 警告：機殼高溫。請勿在使用過程中觸碰上方散熱鰭片。 UNO-2271G V3 User Manual viii...
  • Page 9 Note 2. “○”indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence. 備考 3.“ － ” 係指該項限用物質為排除項目。 Note 3. The “-” indicates that the restricted substance corresponds to the exemption. UNO-2271G V3 User Manual...
  • Page 10 UNO-2271G V3 User Manual...

  • Page 11: Table Of Contents

    Functionality.......9 Introduction ..................... 10 2.1.1 Base Unit's Internal Connectors ..........10 Figure 2.1 Diagram of Connector Locations on UNO-2271G V3 (Top Side)..............10 Figure 2.2 Diagram of Key Components Location on UNO-2271G (Bottom Side)............10 Table 2.1: Key Components, Connectors on Motherboard ..11 2.1.2...
  • Page 12 Figure A.4 Power & Performance ..........52 Figure A.5 CPU – Boot Performance Mode....... 53 Figure A.6 PCH-FW Configuration..........54 Figure A.7 TPM Device Selection ..........55 Figure A.8 ACPI Settings ............55 Figure A.9 NCT61260 Super IO Configuration ......56 UNO-2271G V3 User Manual...
  • Page 13 Figure A.23BTB2 ................ 65 Figure A.24SATA Configuration..........65 A.10.5 Security ..................66 Figure A.25Security ..............66 A.10.6 Boot Options ................67 Figure A.26Boot Options............. 67 A.10.7 Save and Exit................67 Figure A.27Save and Exit ............67 xiii UNO-2271G V3 User Manual...
  • Page 14 UNO-2271G V3 User Manual...

  • Page 15: Chapter 1 Overview

    Chapter Overview This chapter overviews specifica- tions for UNO-2271G V3.  Introduction  Safety Precautions  Accessories  Hardware Specifications  Dimensions...

  • Page 16: Introduction

    The new integrated Din-rail mounting kit is designed to be more ruggedized and user-friendly, making it a perfect fit for control cabinets. This new UNO-2271G V3 model features a ruggedized design with an industrial- grade Intel® Atom Dual core x7211RE processor and built-in onboard 8GB LPDDR5 and 64GB eMMC.

  • Page 17: Packing List

    Stand/Wall mount (Optional Din-rail mount/VESA mount) 10 - 30V Power Requirement 12W (typical), 40W (Max) with 2nd stack expansion module (UNO-2271G-RP1EB): Power Consumption Max to 33.3W (PoE input Max to 25.5W) with 2nd stack expansion module (UNO-2271G-RS2EB): Max to 34.8W UNO-2271G V3 User Manual...

  • Page 18: System Hardware

    Optional: 1 x M.2 B+M key 2242 (SATA/PCIe) Expansion 1 x M.2 B+M key 2242 (SATA/PCIe) Note: There's no SIM card holder on UNO-2271G V3 mainboard. To support M.2 LTE/5G functions, need additionally add 2nd stack extension kit. UNO-2271G V3 User Manual...

  • Page 19: I/O Interfaces

    10~95% RH @ 40° C/104° F, non-condensing Shock Protection Operating, IEC 60068-2-27, 50G, half sine, 11ms Vibration Protection Operating, IEC 60068-2-64, 2Grms, random, 5 ~500Hz Ingress Protection IP30 1.4.5 Certification Table 1.5: Certification Certification CE, FCC, UL, CCC, BSMI UNO-2271G V3 User Manual...

  • Page 20: Extension Kit (Optional)

    1.4.6 Extension Kit (Optional) UNO-2271G V3 features a modularized design. Advantech offers two optional 2nd stack extension kits for users to expand the functionality using an Advantech iDoor module. Table 1.6: UNO-2271G-RP1EB Part number UNO-2271G-RP1EB Description 2nd stack extension kit to support POE PD, COM, M.2 B key Ports 1 x POE (802.3AT), 1 x COM...

  • Page 21: Dimensions

    30 x 70 x 100 mm (11.8 x 27.6 x39.3 in) Weight 0.1 kg (0.22 lbs) Note! Most of the iDoor modules can handle system operating temperatures of 60° C (140° F). (Exception: PoE iDoor, USB 3.0 iDoor). Dimensions Figure 1.1 UNO-2271G V3 Dimensions UNO-2271G V3 User Manual...
  • Page 22 UNO-2271G V3 User Manual...

  • Page 23: Chapter 2 Hardware Functionality

    Chapter Hardware Functionality This chapter details setup instruc- tions for UNO-2271G V3’s hard- ware functions. It includes connecting peripherals and indi- cators.  Introduction  External I/O Connector  Internal I/O Connector  LED Indicators  Reset Buttons  Antenna Hole...

  • Page 24: Introduction

    The following diagram demonstrates the location of UNO-2271G V3’s motherboard and extension kit’s internal/external connectors. 2.1.1 Base Unit's Internal Connectors Figure 2.1 Diagram of Connector Locations on UNO-2271G V3 (Top Side) Figure 2.2 Diagram of Key Components Location on UNO-2271G V3 (Bottom Side) UNO-2271G V3 User Manual...

  • Page 25: Base Unit's External I/O Connector

    BTB1 2nd stack connector BTB2 reserved M.2 Key B Connector for Storage / M.2-B1 iDoor expansion 2.1.2 Base Unit's External I/O Connector Figure 2.3 Front I/O of UNO-2271G V3 Figure 2.4 Side I/O of UNO-2271G V3 UNO-2271G V3 User Manual...

  • Page 26: Expansion Kit's Internal Connectors (Optional)

    2.1.2.3 USB Connector UNO-2271G V3 features 2 x USB ports for Rev. 3.2 specifications. The USB connec- tors support plug-and-play and hot-swap-ping functionality for external devices. Addi- tionally, this can be enabled/disabled in the BIOS menu. (Please refer to User Manual- Appendix A.3 for pin assignments.)
  • Page 27 Figure 2.6 Locations Internal I/O Connectors/Switches for UNO-2271G-RS2EB (Bottom Side) (Optional) Figure 2.7 Locations Internal I/O Connectors/Switches for UNO-2271G-RP1EB (Top Side) (Optional) UNO-2271G V3 User Manual...
  • Page 28 Function COM Port Terminal Connector (RS232/422/485) CN37 LAN Signal Connector M.2 B key for 2242/3042/3052 Connector CN40 M.2 E key for 2230 Connector SIM card slot SW8/SW1 COM port setting switch Internal board to board Connector UNO-2271G V3 User Manual...
  • Page 29 2.1.3.2 COM Connector The second stack extension kit of UNO-2271G V3 provides has 2 COM RS232/422/ 485 ports of terminal block type. They offer transmission speeds of 50 ~115.2 kbps. The default mode for both COM ports (COM1&COM2) is RS-232 Mode. Settings can be adjusted via an on-board switch (SW1).
  • Page 30 UNO-2271G V3 User Manual...

  • Page 31: Chapter 3 Initial Setup

    Chapter Initial Setup This chapter explains how to Ini- tialize the UNO-2271G V3.  Chassis Grounding  Connecting Power  Open and Close Bottom Cover  Installing a 2nd Stack Extension  Installing Internal Component  Antenna Installation (Optional)  BIOS Settings...

  • Page 32: Chassis Grounding

    Chassis Grounding UNO-2271G V3 provides EMI protection and a stable grounding base and there is an easy-to-connect chassis grounding point for this purpose. Figure 3.1 Chassis Grounding Connection Diagram Use the grounding cable (16 AWG) from the accessory bag to connect the chassis ground with the Earth ground.

  • Page 33: Open And Close Bottom Cover

    Open and Close Bottom Cover The steps for opening and closing the bottom cover of UNO-2271G V3 are demon- strated below. Unscrew (1930008736*4) & stopper (1990036188S000*1). Remove BTM cover(1960101339N011*1). UNO-2271G V3 User Manual...

  • Page 34: Install M.2 B+M To E Key Converter (Optional)

    3.3.1 Install M.2 B+M to E Key Converter (Optional) Unscrew (1930001062*1) & remove Bracket (1960102502T000) Install B to E card & lock screw (1930001062*1) UNO-2271G V3 User Manual...
  • Page 35 Install E card & lock screw (1930008738*1) Remove AL Chunk (1960116779N000*1)&screw(1930005541*1) UNO-2271G V3 User Manual...

  • Page 36: Installing A 2Nd Stack Extension Kit (Optional)

    Installing a 2nd Stack Extension Kit (Optional) 3.4.1 Pre-work before 2nd Stack Assembly Unscrew (1930008736*4) &stopper (1990036188S000*1) Remove BTM cover(1960101339N011*1) Remove AL Chunk(1960116779N000*1)&screw(1930005541*1) UNO-2271G V3 User Manual...

  • Page 37: Installing A 2Nd Stack Extension Kit (Uno-2271G-Ekde)

    3.4.2 Installing a 2nd Stack Extension Kit (UNO-2271G-EKDE) Re-- install Al Chunk(1960116779N000*1) & lock screw(1930005541*1) UNO-2271G V3 User Manual...
  • Page 38 Install EXP rear cover(1960116833N001*1) & Lock screw (1930008736*3). Install EXP front cover(1960101372N002*1) & Lock screw (1930008736*2). UNO-2271G V3 User Manual...
  • Page 39 Put on BTM cover(1960101339N011*1). Lock screw (1930008736*3) &stopper (1990036188S000*3). UNO-2271G V3 User Manual...

  • Page 40: Installing A 2Nd Stack Extension Kit (Uno-2271G-Rp1Eb)

    3.4.3 Installing a 2nd Stack Extension Kit (UNO-2271G-RP1EB) Re-install Al Chunk(1960116779N000*1) & lock screw (1930005541*1) UNO-2271G V3 User Manual...
  • Page 41 Install UNO-2271G-RP1EB & Lock screw (1930008736*3). UNO-2271G V3 User Manual...
  • Page 42 Put on BTM cover(1960101339N011*1). Lock screw (1930008736*3) & stopper (1990036188S000*3). UNO-2271G V3 User Manual...

  • Page 43: Installing A 2Nd Stack Extension Kit (Uno-2271G-Rs2Eb)

    3.4.4 Installing a 2nd Stack Extension Kit (UNO-2271G-RS2EB) Re-install Al Chunk(1960116779N000*1) & lock screw(1930005541*1). UNO-2271G V3 User Manual...
  • Page 44 Install UNO-2271G-RS2EB & Lock screw (1930008736*3) (for M.2 LTE or 5G must be install) AL Chunk(1960117266N000*1) Lock screw (1930005541*1) &Put on the thermal Pad (1990041984N000*1) UNO-2271G V3 User Manual...
  • Page 45 UNO-2271G V3 User Manual...
  • Page 46 Put on BTM cover(1960101339N011*1). Lock screw (1930008736*3) &stopper (1990036188S000*3). UNO-2271G V3 User Manual...

  • Page 47: Installing Internal Component

    Installing Internal Component 3.5.1 Installing M.2 2242 Module Unscrew (1930008736*4) &stopper (1990036188S000*1). Remove BTM cover(1960101339N011*1). UNO-2271G V3 User Manual...
  • Page 48 Unscrew (1930008738*1). Insert 2242 module & Lock screw (1930008738*1). UNO-2271G V3 User Manual...

  • Page 49: Installing The M.2 B-Key Module On Extension Kit (Uno-2271G- Rp1Eb/Uno-2271G-Rs2Eb)

    Installing the M.2 B-Key Module on Extension Kit (UNO- 2271G-RP1EB/UNO-2271G-RS2EB) Installing M.2 3042 card Remove the pre-installed screw. Insert the M.2 3042 card at the location of “CN2” and lock the screw. Installing M.2 3052 card Remove the pre-installed screw. UNO-2271G V3 User Manual...

  • Page 50: Installing The M.2 E-Key Module On Extension Kit (Uno-2271G- Rs2Eb)

    Insert the M.2 3042 card at the location of “CN2” and lock the screw. 3.5.3 Installing the M.2 E-key Module on Extension Kit (UNO-2271G- RS2EB) Installing M.2 2230 card Remove the pre-installed screw. UNO-2271G V3 User Manual...

  • Page 51: Antenna Installation (Optional)

    Insert the M.2 2230 card at the location of “CN40” and lock the screw. Antenna Installation (Optional) UNO-2271G V3 reserves pre-cut antenna hole for wireless connection. Follow the steps below for installation the SMA cable and antenna. Unscrew (1930008736*4) & stopper (1990036188S000*1).

  • Page 52: Bios Setting

    Press the “ESC” key upon the first boot up to enter the BIOS setup screen, after then, press the “Del” key during the Power On Self Test (POST) process to enter the BIOS setup screen, otherwise the system will continue the POST process. (Please refer to User Manual- Appendix A.10) UNO-2271G V3 User Manual...

  • Page 53: Appendix A System Settings/Pin Assignments

    Appendix System Settings/Pin Assignments...

  • Page 54: Power Connector (Dcin1)

    MDI[2]+/- corresponds to BI_DC+/- and MDI[3]+/ - corresponds to BI_DD+/-. MDI3+ 100BASE-TX: Unused.  MDI3- 10BASE-T: Unused.  Table A.3: LAN LED Light Definition Left LED Right LED 10Mbps 100Mbps 1000Mbps 2500Mbps Active (Green Link (Green) (off) (off) (Orange) (Green) Flash) UNO-2271G V3 User Manual...

  • Page 55: Usb Connector (Usb1)

    Table A.4: USB 3.2 Connector Pin Assignments Signal Name Description VBUS Power USB 2.0 differential pair Ground for power return StdA_SSRX- SuperSpeed receiver differential pair StdA_SSRX+ GND_DRIAN Ground for signal return StdA_SSTX- SuperSpeed transmitter differential pair StdA_SSTX+ UNO-2271G V3 User Manual...

  • Page 56: Usb Type C

    A.3.2 USB Type C Table A.5: USB Type C Signal Name Signal Name USBC_TXPO_CON USBC_RXPO_CON USBC_TXNO_CON USBC RXNO CON +V5BUS_CON +V5BUS_CON CCG5_CC1_CON USBC_SBU2_CON USB2_PCH_TYPEC1_a_D_P USB2_PCH_TYPEC1_a_D_N USB2_PCH_TYPEC1_a_D_N USB2_PCH_TYPEC1_a_D_P USBC_SBU1_CON CCG5_CC2_CON +V5BUS_CON +V5BUS_CON USBC_RXN1_CON USBC_TXN1_CON USBC_RXP1_CON USBC_TXP1_CON UNO-2271G V3 User Manual...

  • Page 57: Hdmi Connector (Hdmi1)

    HDMI Connector (HDMI1) Table A.6: Display Port Adapter Cable Pin Assignments Signal Name TMDS1_a_P0 TMDS1_a_N0 TMDS1_a_P1 TMDS1_a_N1 TMDS1_a_P2 TMDS1_a_N2 TMDS1_CLK_a_P TMDS1_CLK_a_N TMDS1_DDCCLK TMDS1_DDCDAT TMDS1_HPD UNO-2271G V3 User Manual...

  • Page 58: M.2 B-Key Connector (M.2_B1)

    Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B Mechanical notch B WAKE_ON_WAN# M2_LTE_W2_DISABLE_N USB_Z_SSRX1- M2_SIM1_RESET USB_Z_SSRX1+ M2_SIM1_CLK M2_SIM1_DATA USB_C_SSTX1- M2_SIM1_PWR USB_C_SSTX1+ M2_SIM2_DET SATA1_RX+ SATA1_RX- SATA1_C_TX- SATA1_C_TX+ M2_SIM1_DET LTE_RST#_P67 UNO-2271G V3 User Manual...

  • Page 59: M.2 E-Key Connector (Cn40)

    Mechanical notch E Mechanical notch E Mechanical notch E Mechanical notch E Mechanical notch E Mechanical notch E Mechanical notch E Mechanical notch E PCIE_M2_TX1+ PCIE_M2_TX1- PCIE_M2_RX1+ PCIE_M2_RX1- CLK_M2_PCIE1+ CLK_M2_PCIE1- M2E_SUSCLK M2E_PERST0# M2E_CLKREQ0# M2E_z_W_DISABLE2# M2E_PEWAKE0# M2E_z_W_DISABLE1# UNO-2271G V3 User Manual...

  • Page 60: Com Port Rs232/422/485 Settings

    Signal Name COM2 Mode Signal Name RS232 RS232 RS422 RS422 RS485 RS485 RS232 RS232 RS422 RS422 RS485 RS485 RS232 RS232 RS422 RS422 RS485 RS485 RS232 RS232 RS422 RS422 RS485 RS485 RS232 RS232 RS422 RS422 RS485 RS485 UNO-2271G V3 User Manual...

  • Page 61: Rs232/422/485 Setting (Sw8/Sw1)

    Bit 1,3,6,7,8,9,10 OFF Bit 1,2,4,5 ON RS422 Mode Bit 3,6,7,8,9,10 OFF Bit 6 ON RS232 Mode Bit 1,2,3,4,5,7,8,9,10 OFF Bit 7,9,10 ON COM2 RS485 Mode Bit 1,2,3,4,5,7,8 OFF Bit 6,7,9,10 ON RS422 Mode Bit 1,2,3,4,5,8 OFF UNO-2271G V3 User Manual...

  • Page 62: Com Port Rs422/485 Termination Resistor Setting

    AT/ATX Setting(SW4) SW4 can be used for AT/ATX setting. The default setting is AT mode. See the follow- ing table for switching configuration Table A.12: AT/ATX Setting (SW4) Description Instruction AT mode (default) PIN1-PIN2 ATX mode PIN2-PIN3 UNO-2271G V3 User Manual...

  • Page 63: Clear Cmos Setting (Sw3)

    Signal Name Signal Name ESPI_CLK ESPI_ALERT0# ESPI_IO0 ESPI_IO1 ESPI_IO2 ESPI_IO3 ESPI_CS0# ESPI_RST0# PMC_SUSCLK PMC_SLP_S3# GP_H00 PCIE_WAKE# PLTRST_M.2# M2B1_CLKREQ2# USB2_P0+ USB2_P0- USB2_P4+ USB2_P4- CLK100M_M2E1_D2+ CLK100M_M2E1_D2- PCIE4_TX+ PCIE4_TX- PCIE4_RX+ PCIE4_RX- SATA1_TX+ SATA1_TX- SATA1_RX+ SATA1_RX- USB31_P2_TX+ USB31_P2_TX- USB31_P2_RX+ USB31_P2_RX- UNO-2271G V3 User Manual...

  • Page 64: Bios Operation

    The Setup Utility uses a number of menus for making changes and turning the specific features on or off. This chapter describes the basic navigation of the UNO-2271G V3 setup screens. AMI’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration.

  • Page 65: Advanced Bios Features

    HH:MM:SS format A.10.3Advanced BIOS Features Setup Select the Advanced tab from the UNO-2271G V3 setup screen to enter the Advanced BIOS setup screen. You can select any of the items in the left frame of the screen, such as CPU configuration, to go to the sub menu for that item. You can dis- play an Advanced BIOS Setup option by highlighting it using the keys.
  • Page 66 A.10.3.1CPU Configuration Figure A.3 CPU Configuration A.10.3.2Power & Performance Figure A.4 Power & Performance UNO-2271G V3 User Manual...
  • Page 67 Select the performance state that the BIOS will set starting from reset vector. Intel® SpeedStep(tm)  Allows more than two frequency ranges to be supported Turbo mode  C states  Enable/Disable CPU Power Management. Allows CPU to go to C states when it’s not 100% utilized. UNO-2271G V3 User Manual...
  • Page 68 A.10.3.3PCH-FW Configuration Figure A.6 PCH-FW Configuration UNO-2271G V3 User Manual...
  • Page 69 Figure A.7 TPM Device Selection Select TPM device  fTPM or dTPM. fTPM -Enables fTPM. dTPM-Disable fTPM and Enable dTPM. Warnin: fTPM/dTPM will be disabled and all data saved on it will be lost. A.10.3.5ACPI Settings Figure A.8 ACPI Settings UNO-2271G V3 User Manual...
  • Page 70 A.10.3.6NCT6126D Super IO Configuration Figure A.9 NCT61260 Super IO Configuration Serial Port 1 Configuration  Set Parameters of Serial Port 1. Figure A.10 Serial Port 1 Configuration UNO-2271G V3 User Manual...
  • Page 71 Serial Port 2 Configuration  Set Parameters of Serial Port 2. Figure A.11 Serial Port 2 Configuration UNO-2271G V3 User Manual...
  • Page 72 Figure A.12 S5 RTC Wake Settings Wake System from S5  Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. Select DynamicTime, System will wake on current time + Increase minute(s). UNO-2271G V3 User Manual...
  • Page 73 Mass Storage Devices: USB  Mass storage device emulation type. “AUTO” enumerates devices according to their media format. Optical drives are emulated as “CDROM”, drives with no media will be emulated according to a drive type. UNO-2271G V3 User Manual...
  • Page 74 A.10.3.9Network Stack Settings Figure A.14 Network Stack Configuration Network Stack  Enable/Disable UEFI Network Stack. A.10.4Chipset Figure A.15 Chipset UNO-2271G V3 User Manual...
  • Page 75 A.10.4.1System Agent(SA) Configuration System Agent (SA) Configuration  Figure A.16 System Agent (SA) Configuration Figure A.17 Memory Configuration UNO-2271G V3 User Manual...
  • Page 76 Figure A.18 PCH-IO Configuration PCI Express Configuration  – M.2 E-key/LAN 3: for 2 stack extension kit – LAN 1: for Base Unit – LAN 2: for Base Unit – BTB2: for reserved – M.2 B-key: for Base Unit UNO-2271G V3 User Manual...
  • Page 77 Figure A.19 M.2 E-key/LAN 3 Figure A.20 LAN 1 UNO-2271G V3 User Manual...
  • Page 78 Figure A.21 LAN 2 Figure A.22 M.2 B-key UNO-2271G V3 User Manual...
  • Page 79 Figure A.23 BTB2 A.10.4.3SATA Configuration SATA Configuration  SATA Controller(s): Enable/Disable SATA Device. SATA Mode Selection: Determines how SATA controller(s) operate. Aggressive LPM Support: Enable PCH to aggressively enter link power state. Figure A.24 SATA Configuration UNO-2271G V3 User Manual...
  • Page 80 Policy variables can be configured by a physically present user without full authentication. – Restore Factory Keys: Force System to User Mode. Install factory default Secure Boot key databases. – Key Management: Enables expert users to modify Secure Boot Policy vari- ables without full authentication UNO-2271G V3 User Manual...
  • Page 81 A.10.6Boot Options Figure A.26 Boot Options A.10.7Save and Exit Figure A.27 Save and Exit UNO-2271G V3 User Manual...
  • Page 82 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...

This manual is also suitable for:

Uno-2271g-i331aeUno2271gi3312401-tUno2271gi3312402-tUno2271gi3312501-tUno2271gi3312502-tUno2271gi3312503-t ... Show all
