Shuttle Recovery Owner's Manual page 6

II. Assembly Instructions
Assembly of the Shuttle Recovery requires two people. It is recommended that you begin
assembly by opening both box 1 and 2 and familiarizing yourself with the included parts.
Keep in mind that the following images pertain to just one of the four available Shuttle Recovery
models, your parts may appear slightly different than those in the included images but, the
required steps remain the same.
Step 1: Rail Frame Assembly (Box 1)
Step 2: Attach Footend Bracket (Box 1)
Step 3: Attach Support Tubes (Box 2)
Step 4: Attach Left Hand Side Panel
Step 5: Add the Plyometric X Brace (Box 1)
Step 6: Add the Elasticords (Box 1)
Step 7: Attach the Kickplate Frame (Box 2)
Step 8: Add the Kickplate (Box 2)
Step 9: Add the Carriage (Box 2)
Step 10: Headrest (Box 2)
Step 11: Inspect the assembly
Tools
Included:
● 1/4" Allen Wrench
● 3/16" Allen Wrench
● 5/32" Allen Wrench
● Sample of Silicone Gel for lubricating Elasticords every 2-3 months
You will need:
● A friend to help with assembly
● 7/16" open end or box wrench
● 1/2" open end or box wrench
● Optional: 7/16" and 1/2" Socket
