Service Manual
Dismantling
OSPE Steering Valve
Dismantling OSPE (continued)
Screw out the plug (225) using a 5 mm
Remove spool (224) using a 4 mm screw.
Shake out the check valve ball (5), suction valve balls (81),
cone (214) and spring (213).
Place the housing with the ports facing down on the
work bench. Ensure that the cross pin (12) in the spool
and sleeve set (1) is in the horizontal position. The pin
(12) can be observed through the open end of the spool.
L1506577 • Rev 0001 • August 2015
Hex key.
