Service Manual
Dismantling
OSPE Steering Valve
Dismantling OSPE (continued)
Replace the unit in the holding tool on the gear set end.
Use appropriate support made of plastic, brass or
aluminum under the mounting surface for the PVE to
support the steering valve.
Screw out the adjusting screws for shock valves (64)
using a 5 mm
Hex key.
O-ring (40) is fitted on screw (64)
Remove the springs with trust pads for shock valves (62).
Remove the balls for shock valves (61).
L1506577 • Rev 0001 • August 2015
15
