Construction, Controls and Cabling
• Compact design: 5.5" x 3.5" x 1.5" (14 x 9 x 4 cm).
• Light weight: less than 12 oz (340 g).
• Solid anodized aluminum case.
• Thick rubber end boots for shock protection.
• Ruggedized metal connectors.
• Cable interfaces on sides for easier connections.
• Multiple cable options for vehicle networks, including Ethernet, DoIP and OBD-II.
• Top membrane interface with network and logger status LEDs and two pushbuttons.
• Ability to control LEDs and pushbuttons in custom scripts.
Power and Performance
• Fourth-generation neoVI architecture, offering over ten times the performance of earlier
devices.
• Memory updated to 32 MB and on-board flash to 64 MB, allowing much more space for
scripting and buffering.
• Field-upgradeable firmware.
• Support for 4.5V to 40V input power.
• Built-in five-second uninterruptible power supply to ensure graceful shutdown on power
loss.
• Ability to configure device and download SD card data on the desktop using only USB
power.
• Lower power consumption than earlier generation devices.
Network Interfaces and Features
• 6 dedicated DW CAN channels (ISO 11898-2): 5 Dual Wire HS CAN, 1 Dual Wire MS
CAN.
• 2 selectable CAN channels: 2 additional Dual Wire HS CAN, or 2 Single Wire SW CAN,
or 2 Low Speed Fault Tolerant LSFT CAN (ISO 11898-3).
• All Dual Wire CAN channels have CAN FD support.
• Initial support for non-ISO CAN FD, with ISO CAN FD upgrade included when it is
available.
