• Software-programmable CAN termination.
• 4 LIN channels.
• 2 MISC I/O channels, which can be configured as analog / PWM.
• Software-configurable CAN and LIN channel enables/disables, baud rates and other
parameters.
• 10/100 Ethernet with low power mode and activation line.
• Ethernet link usable for DoIP/XCP, or to connect to Automotive Ethernet (BroadR-Reach
/ 100BASE-T1) network through Intrepid RAD-Moon (sold separately).
• Real-time clock for 64-bit message timestamping.
Logging and Simulation
• Fully-programmable scripting and standalone logging functionality.
• SD card logging of all traffic.
• Software-configurable sleep mode.
• Low power modes.
• Comatose support; device wakeup can be triggered by all 12 CAN transceivers, all 4
LIN channels, by USB or by the membrane keypad.
PC Interface and SD Card Support
• High-speed isolated USB connection protects PC from potential damage.
• Support for microSD cards up to 128 GB in size.
• Data can be unloaded from the microSD card via USB without the need to remove the
card, or via the included card reader.
• Download speeds of up to 3.2 MB/s.
• Firmware-based SD card presence and card door detector.
Advanced Features
• Device control by external software using three open APIs: neoVI DLL, SAE J2534, and
TMC RP1210 A/B.
• USB host slot for hardware expandability, such as powering a RAD-Moon or using a
neoVI MIC microphone/trigger pendant.
