Vehicle
Networks
Figure 47: FIRE 2 Hardware Hookup Diagram with neoVI-OBD-1 Cable.
OBD Hardware Hookup Diagram - neoVI-OBD-MULTI Cable
Figure 48 shows the hardware setup using the neoVI-OBD-MULTI cable.
Vehicle
Networks
Figure 48: FIRE 2 Hardware Hookup Diagram with neoVI-OBD-MULTI Cable.
OBD Hardware Hookup Diagram - neoVI-OBD-MULTI Right Angle Cable
The hardware setup for the neoVI-OBD-MULTI Right Angle cable is the same as that of the
neoVI-OBD-MULTI, except the OBD connector is at a right angle to the cable for use where
this is convenient (Figure 49).
