Table 2: FIRE 2 Top Membrane Blue Set LED Meanings.
"White Set" LED Status Indicators
Table 3 lists the white labels/icons on the FIRE 2 membrane interface, and describes the
meaning of the LEDs for each when the white set is selected (bottom right keypad button
flashing). Again the LEDs are listed from top to bottom, left to right.
Table 3: FIRE 2 Top Membrane White Set LED Meanings.
2.5

Standard Cables and Cable Options

As mentioned in Section 1.2, the FIRE 2 ships with several standard cables, as well as one of
five optional OBD cables that was selected when the device was ordered. We'll now illustrate
these cables and describe each one's use. Connector pinouts and cable signal tables for this
hardware can be found in Chapter 7 (except for the USB cable, which is industry standard).
Version 2.1 - October 10, 2016
neoVI FIRE 2 User's Guide
Label
HSCAN1
HSCAN2
MSCAN
HSCAN3
HSCAN4
DoIP
LINS
CAN7
Label/Icon
HSCAN5
CAN8
Description
Transmit / receive / error status of HS CAN channel 1
Transmit / receive / error status of HS CAN channel 2
Transmit / receive / error status of MS CAN channel
Transmit / receive / error status of HS CAN channel 3
Transmit / receive / error status of HS CAN channel 4
Transmit / receive / error status of Ethernet channel
Status of all LIN channels
Transmit / receive / error status of HS CAN channel 6, SW
CAN channel 2, or LSFT CAN channel 1, depending on
CAN mode selected (see Section 4.5)
Description
CoreMini script active
Disk (solid state drive) activity
Data being uploaded
Logging a triggered collection
after the trigger condition has activated
GPS lock (using neoVI MIC2, available later in 2016)
General purpose, user-programmable
Transmit / receive / error status of HS CAN channel 5
Transmit / receive / error status of HS CAN channel 7, SW
CAN channel 1, or LSFT CAN channel 2, depending on
CAN mode selected (see Section 4.5)
15 © 2016 Intrepid Control Systems, Inc.
