neoVI FIRE 2 User's Guide
neoVI-OBD-MULTI Right Angle Cable
This is the same as the neoVI-OBD-MULTI cable but terminates with a right-angled OBD II
connector for vehicles where this is required. A picture of the cable is shown in Figure 18.
Figure 18: neoVI-OBD-MULTI Right Angle Cable.
neoVI FIRE/RED J1939 Cable
This cable terminates in a round 9-pin Deutsch connector for use in commercial vehicles
(Figure 19).
Figure 19: neoVI FIRE/RED J1939 Cable.
Version 2.1 - October 10, 2016
21
© 2016 Intrepid Control Systems, Inc.
