Enabled
Place a checkmark in this box to enable the channel, or clear the checkmark to disable it.
When disabled, all of the other parameter controls are disabled (grayed out).
Baud Rate
Select a baud rate for the channel; the default is 10417.
Mode
This option is currently not used and should be left at the default of "Normal Mode".
Master Resistor On
Enable this option for the neoVI FIRE 2 to act as the master on the specified LIN bus.
Advanced Options
Click this checkbox to reveal two additional options:
• Master Slave Interval: The time between the master ID and the first slave byte, in bits
(default 0).
• Verbose Error Reporting: When checked, break errors and other error messages from
the LIN driver are displayed.
4.7

MISC IO

This section contains parameters controlling the neoVI FIRE 2's miscellaneous I/O channels.
Reporting parameters can be found within the main "MISC IO" entry, while others are
contained in two subordinate panels in the explorer navigation tree.
Reporting Parameters
These parameters allow you to control reporting related to miscellaneous I/O channels
(Figure 72):
• Report on Period: Enable this option and select a time interval to turn on periodic
reporting.
• Report GPS Coordinates: Check this box to enable GPS support.
• Report on Change: Check the boxes of the channels for which you want detected
value changes to trigger a report.
• Analog Threshold: Set the analog threshold percentage value (default is 10%).
