DB-25 Connector Pinout
Table 10 shows the pinout of the DB-25 connector on the neoVI-OBD-1.
Table 10: neoVI-OBD-1 Cable DB-25 Connector Pinout.
OBD-II / J1962 Connector Pinout
Table 11 contains the pinout for the OBD-II / J1962 connector on this cable.
Version 2.1 - October 10, 2016
neoVI FIRE 2 User's Guide
Pin # Name
1 SW CAN
2 N/C
3 N/C
4 N/C
5 MS CAN H
6 MS CAN L
7 ISO L
8 ISO9141/K/LIN1
9 N/C
10 N/C
11 N/C
12 N/C
13 GND
14 HS CAN 1 H
15 HS CAN 1 L
16 HS CAN 2 H
17 HS CAN 2 L
18 N/C
19 HS CAN 3 H
20 HS CAN 3 L
21 N/C
22 N/C
23 N/C
24 N/C
25 V BATT
Description
Single Wire CAN channel
No connection
No connection
No connection
Medium Speed CAN channel, high
Medium Speed CAN channel, low
ISO 9141-2 L-Line
ISO 9141-2 K-Line / LIN channel 1
No connection
No connection
No connection
No connection
Ground
High Speed CAN channel 1, high
High Speed CAN channel 1, low
High Speed CAN channel 2, high
High Speed CAN channel 2, low
No connection
High Speed CAN channel 3, high
High Speed CAN channel 3, low
No connection
No connection
No connection
No connection
DC Input Power
