Table 16: neoVI FIRE/RED J1939 Cable DB-25 Connector Pinout.
Deutsch 9-Pin Connector Pinout
The pinout for the Deutsch connector on this cable is found in Table 17.
Table 17: neoVI FIRE/RED J1939 Cable Deutsch 9-Pin Connector Pinout. The table shows standard signals for the
Deutsch 9-pin connector; this includes J1708, which is not supported by the NEOVI FIRE 2.
Cable Signal Mapping
Table 18 contains the mapping of signals for the neoVI FIRE/RED J1939 cable. The signal
names for both connectors are shown and the table is based on the Deutsch 9-pin connector's
pin order.
Version 2.1 - October 10, 2016
neoVI FIRE 2 User's Guide
Pin # Name
12 N/C
13 GND
14 HS CAN H
15 HS CAN L
16 N/C
17 N/C
18 N/C
19 N/C
20 N/C
21 N/C
22 N/C
23 N/C
24 N/C
25 V BATT
Pin # Name
1/A Ground (-)
2/B Battery (+)
3/C CAN High (+)
4/D CAN Low (-)
5/E CAN Shield
6/F J1708 (+)
7/G J1708 (-)
8/H CAN2 High (+)
9/J CAN2 Low (-)
Description
No connection
Ground
High Speed CAN channel, high
High Speed CAN channel, low
No connection
No connection
No connection
No connection
No connection
No connection
No connection
No connection
No connection
DC Input Power
Description
Ground
Battery Power
High Speed CAN channel 1, high
High Speed CAN channel 1, low
CAN shield
J1708 channel, high
J1708 channel, low
High Speed CAN channel 1, high
High Speed CAN channel 1, low
