Intrepid Control Systems neoVI FIRE 2 User Manual page 83

Table 19: FIRE 2 OBD Cable with DoIP Support DB-25 Connector Pinout.
DB-9 Connector Pinout
Table 20 contains the pinout for the DB-9 connector on this cable.
Table 20: FIRE 2 OBD Cable with DoIP Support DB-9 Connector Pinout.
Version 2.1 - October 10, 2016
neoVI FIRE 2 User's Guide
Pin # Name
12 N/C
13 GND
14 HS CAN 4 H
15 HS CAN 4 L
16 HS CAN 2 H
17 HS CAN 2 L
18 N/C
19 HS CAN 3 H
20 HS CAN 3 L
21 N/C
22 N/C
23 N/C
24 N/C
25 V BATT
Pin # Name
1 LIN 1
2 LIN 2
3 LIN 3
4 ETH ACTIVATE
5 GND
6 N/C
7 N/C
8 N/C
9 N/C
Description
No connection
Ground
High Speed CAN channel 4, high
High Speed CAN channel 4, low
High Speed CAN channel 2, high
High Speed CAN channel 2, low
No connection
High Speed CAN channel 3, high
High Speed CAN channel 3, low
No connection
No connection
No connection
No connection
DC Input Power
Description
LIN channel 1
LIN channel 2
LIN channel 3
Ethernet activation line
Ground
No connection
No connection
No connection
No connection
79 © 2016 Intrepid Control Systems, Inc.
