OBD-II / J1962 Connector Pinout
Table 21 shows the pinout for the OBD-II / J1962 connector on the cable.
Table 21: FIRE 2 OBD Cable with DoIP Support OBD-II / J1962 Connector Pinout.
Cable Signal Mapping
Table 22 shows the mapping of signals for the FIRE 2 OBD Cable with DoIP Support, ordered
by pin number on the HD-26 that connects to the FIRE 2.
Version 2.1 - October 10, 2016
neoVI FIRE 2 User's Guide
Pin #
Name
1
MS CAN H
2
N/C
3
ETH TX+
4
N/C
5
GND
6
HS CAN H
7
N/C
8
ETH ACTIVATE
9
MS CAN L
10
N/C
11
ETH TX-
12
ETH RX+
13
ETH RX-
14
HS CAN L
15
N/C
16
VBATT
Description
Medium Speed CAN channel, high
No connection
Ethernet transmit channel, positive
No connection
Ground
High Speed CAN channel, high
No connection
Ethernet activation line
Medium Speed CAN channel, low
No connection
Ethernet transmit channel, negative
Ethernet receive channel, positive
Ethernet receive channel, negative
High Speed CAN channel, low
No connection
DC power input
80
© 2016 Intrepid Control Systems, Inc.
