Configuring

5.1

Configuring the F-CM AS-i Safety ST

Notes on configuration
You configure the ET 200SP station and its F-CM AS-i Safety ST module and assign their
parameters with
There is currently no provision for configuration via a GSD file, because the GSD
configuration procedure does not permit safety-related parameter assignment (according to
PROFIsafe Specification V2.4).
Note
F-CM AS-i Safety ST in the hardware catalog of
If the F-CM AS-i Safety ST module is not listed in the hardware catalog of
need a "Hardware Support Package". This HSP can be obtained from the Internet using the
corresponding function in
Note
Operation under S7 F systems is not approved.
Note
The data exchange with "F-DX-MOD" is not supported.
Software for configuration of the F-CM AS-i Safety ST
Configuration software
STEP 7
(classic) V5.5 SP3 HF4 or
higher with Distributed Safety
STEP 7
(classic) V5.5 SP4 or higher
with Distributed Safety
STEP 7
(TIA Portal) V13 or higher with
Safety Advanced
STEP 7
(TIA Portal) V14 or higher with
Safety Advanced / Basic
Download optional, if not already contained in the hardware catalog
1)
Fail-safe Module F‑CM AS‑i Safety ST (3RK7136‑6SC00‑0BC1)
Manual, 03/2017, A5E03957059020A/RS-AB/002
STEP 7
.
STEP 7
.
Requirements
Hardware Support Package HSP 2093
Internet
Hardware Support Package HSP 70
Internet
(http://support.automation.siemens.com/W
W/view/en/29156492/133100)
STEP 7
Installation information
Online Help for
1)
1)
5
STEP 7
, you will
STEP 7
33
