User Interface

4.1.2 Setting LCP Display Values

The display area is activated when the frequency converter
receives power from mains voltage, or an external 24 V
supply.
The information displayed on the LCP can be customized
for user application.
4 4
•
Each display readout has a parameter associated
with it.
•
The frequency converter status at the bottom line
of the display is generated automatically and is
not selectable. See 6.3 Status Message Definitions
Table for more information.
Display
1.1
1.2
1.3
2
3
Status
799 RPM
1.1
1.2
Auto Remote Ramping
2
Status
207RPM
1.1
Auto Remote Running
34
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
VLT
Parameter number Default setting
0-20 Motor RPMs
0-21 Motor current
0-22 Motor power (kW)
0-23 Motor frequency
0-24 Reference in percent
0.98 A
0.000
53.2 %
1.3
3
0.98 A
6.9
Hz
MG04F302 - VLT
®
Decentral Drive FCD 302 Operating Instructions

4.1.3 Display Menu Keys

Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
Status
Key
Status
Quick Menu
1 (1)
0.75 kW
Main Menu
Alarm Log
1 (1)
0.75 kW
1.3
1.2
2
®
is a registered Danfoss trademark
Quick Main
Menu Menu
Function
Shows operational information.
•
In Auto mode, press to toggle between
status read-out displays
•
Press repeatedly to scroll through each
status display
•
▲ ▼
Press [Status] plus [ ] or [ ] to adjust the
display brightness
•
The symbol in the upper right corner of the
display shows the direction of motor
rotation and which set-up is active. This is
not programmable.
Allows access to programming parameters for
initial set up instructions and many detailed
application instructions.
•
Press to access Q2 Quick Setup for
sequenced instructions to program the basic
frequency controller set up
•
Follow the sequence of parameters as
presented for the function set up
Allows access to all programming parameters.
•
Press twice to access top-level index
•
Press once to return to the last location
accessed
•
Press to enter a parameter number for
direct access to that parameter
Displays a list of current warnings, the last 10
alarms, and the maintenance log.
•
For details about the frequency converter
before it entered the alarm mode, select the
alarm number using the navigation keys
and press [OK].
Alarm
Log
