Installation
2 2
1
Illustration 2.22 Installation to Achieve a Stopping Category 0 (EN 60204-1) with Safety Cat. 3 (EN 954-1) / PL "d" (ISO 13849-1).
1 Safety device Cat. 3 (circuit interrupt device, possibly
with release input)
2 Door contact
3 Contactor (Coast)
4 Frequency converter
5 Mains
6 Control board
28
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
®
VLT Decentral Drive FCD 302 Operating Instructions
3
2
11
10
7 Inverter module
8 Motor
9 5 V DC
10 Safe channel
11 Short-circuit protected cable (according to ISO 13849-2 table D.4)
®
MG04F302 - VLT is a registered Danfoss trademark
