Programming
Par. Parameter description
No. #
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
3-82 Quick Stop Ramp Type
3-83 Quick Stop S-ramp Ratio at Decel. Start
3-84 Quick Stop S-ramp Ratio at Decel. End
3-9* Digital Pot.Meter
3-90 Step Size
5 5
3-91 Ramp Time
3-92 Power Restore
3-93 Maximum Limit
3-94 Minimum Limit
3-95 Ramp Delay
46
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
®
VLT Decentral Drive FCD 302 Operating Instructions
Default value
App.Dependent
App.Dependent
[0] Linear
50%
50%
0.10%
1.00 s
[0] Off
100%
-100%
App.Dependent
®
MG04F302 - VLT is a registered Danfoss trademark
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
-2 Uint32
-2 Uint32
- Uint8
0 Uint8
0 Uint8
-2 Uint16
-2 Uint32
- Uint8
0 Int16
0 Int16
-3 TimD
