Installation

CAUTION

PE CONNECTION

The metal pins in the corners of the electronic part and

the holes on the corner of the installation box are essential

for the protective earth connection. Make sure that they

are not loosened, removed, or violated in any way.

Tightening torque requirement is 3 Nm. See

Illustration 2.16.

Illustration 2.16 PE Connection between the Installation Box and

the Electronic Part

NOTE

The external grounding terminal is available as an

accessory (part no: 130B5833).
