Illustration 2.9 Electrical Installation - Danfoss VLT FCD 302 Operating Instructions Manual

Installation
91 (L1)
3 phase
92 (L2)
power
93 (L3)
input
95 (PE)
122(MBR+)
Mechanical
123(MBR-)
brake
50 (+10 V OUT)
+10Vdc
-10Vdc-
53 (A IN)
+10Vdc
0/4-20 mA
-10Vdc-
54 (A IN)
+10Vdc
0/4-20 mA
55 (COM A IN)
12 (+24 V OUT)
13 (+24 V OUT)
18 (D IN)
19 (D IN)
20 (COM D IN)
27 (D IN/OUT)
29 (D IN/OUT)
32 (D IN)
33 (D IN)
37 (D IN)

Illustration 2.9 Electrical Installation

Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
®
VLT Decentral Drive FCD 302 Operating Instructions
Switch Mode
Power Supply
24Vdc
10Vdc
600mA
15mA
S201
ON/I=0-20mA
S202
OFF/U=0-10V
P 5-00
24V (NPN)
OV (PNP)
24V (NPN)
OV (PNP)
24V (NPN)
OV (PNP)
24V (NPN)
OV (PNP)
24V
OV
24V (NPN)
OV (PNP)
24V (NPN)
OV (PNP)
®
MG04F302 - VLT is a registered Danfoss trademark
(U) 96
(U) 97
(W) 98
(PE) 99
(R+) 82
(R-) 81
relay1
03
02
01
relay2
06
05
04
(COM A OUT) 39
(A OT) 42
0V
S801
ON=Terminated
OFF=Open
5V
GX
S801
RS-485
(N RS-485) 69
Interface
(P RS-485) 68
(COM RS-485) 61
GX
VCXA
67
GND1
62
Profibus
interface
63
66
GND1
Motor
Brake
resistor
240Vac, 2A
240Vac, 2A
400Vac, 2A
Analog Output
0/4-20 mA
RS-485
(PNP) = Source
(NPN) = Sink
RS485
