Start Up and Functional Tes...
Inspect for
Input and
output power
wiring
Switches
3 3
Grounding
Installation
box and
electronics
part
Cable glands
and blind
plugs
Vibration
Table 3.1 Start Up Check List
3.2 Applying Power to the Frequency
Converter
WARNING
HIGH VOLTAGE
Frequency converters contain high voltage when
connected to AC mains input power. Only qualified
personnel must perform installation, start-up and
maintenance. Failure to perform installation, start-up and
maintenance by qualified personnel could result in death
or serious injury.
1. Perform pre-start up procedure described in
3.1 Pre-start.
2. Confirm input line voltage is balanced within 3%.
If not, correct input voltage imbalance before
proceeding. Repeat procedure after voltage
correction.
3. Ensure optional equipment wiring, if present,
matches installation application.
4. Ensure that all operator devices are in OFF
position.
30
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
Description
•
Check for loose connections
•
Check for proper fusing or circuit
breakers
Ensure that all switch and disconnect
settings are in the proper position.
The equipment requires a dedicated
ground wire from its chassis to the
plant ground. Check for good ground
connections that are tight and free of
oxidation.
Ensure the installation box and the
electronics part is properly closed.
Check that all four fastening screws are
tightened with the right torque.
Ensure the cable glands and blind
plugs are properly tightened, to
guarantee the right enclosure
protection degree is achieved. Liquids
and/or excessive dust ingress in the
drive can cause sub-optimal
performance or damage.
Ensure the equipment is not exposed
to a high level of vibration. Mount the
panel solidly or use shock mounts as
necessary.
MG04F302 - VLT
®
VLT Decentral Drive FCD 302 Operating Instructions
WARNING
☑
UNINTENDED START
When frequency converter is connected to AC mains input
power, the motor may start at any time. The frequency
converter, motor, and any driven equipment must be in
operational readiness. Failure to be in operational
readiness when the frequency converter is connected to
AC mains could result in death, serious injury, equipment,
or property damage.
5.

3.3 Quick Setup

Frequency converters require basic operational
programming before running for best performance. Basic
operational programming requires entering motor-
nameplate data for the motor being operated and the
minimum and maximum motor speeds. Enter this data in
accordance with the following procedure. See 4 User
Interface, for detailed instructions on entering data through
the LCP. Enter this data with power ON, but before
operating the frequency converter.
1.
2.
13.7%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
3.
®
is a registered Danfoss trademark
Apply power to the unit. DO NOT start the
frequency converter at this time. For units with a
disconnect switch on the mains side, turn to the
ON position to apply power to the frequency
converter.
Press [Quick Menu] on the LCP.
Use the navigation keys to scroll to parameter
group Q2 Quick Setup and press [OK].
0.75A
Select language and press [OK]. Then enter the
motor data in 1-20 Motor Power [kW]/1-21 Motor
Power [HP] through 1-25 Motor Nominal Speed.
The information can be found on the motor
nameplate. The entire quick menu is shown in
International/North American Default Parameter
Settings
1-20 Motor Power [kW]
1-21 Motor Power [HP]
1 (1)
