Status Indication

6 Status Indication

6.1 Frontal LEDs

The actual status can be read on the outside of the FCD
products. Six LEDs signal the actual status of the unit with
the meaning described in Table 6.1.
6 6
Illustration 6.1 Frontal LEDs
Name Colour
ON Green
Warning Yellow
Alarm Red
Bus MS Only relevant if
optional fieldbus is
Bus NS1
present. See Profibus
Bus NS2
manual: MG34NXYY,
Ethernet manual:
MG90JXYY and
ProfiNet manual:
MG90UXYY, for
specific information.
Table 6.1 LED Status

6.2 Status Display

When the frequency converter is in status mode, status
messages are generated automatically from within the
frequency converter and appear in the bottom line of the
display (see Illustration 6.2.)
64
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
VLT
ON Warning Alarm
Bus MS NS1 NS2
Status Indication
On The frequency converter
receives power from mains
voltage, or external 24 V
supply.
Off No power from mains
voltage, or external 24 V
supply.
On Warning situation is present.
Off No warning is present.
Flashing Alarm is present.
Off No alarm is present
Bus Module Status
Bus Network Status 1
Bus Network Status 2
MG04F302 - VLT
®
Decentral Drive FCD 302 Operating Instructions
Status
799RPM
Auto
Hand
a
Illustration 6.2 Status Display
a. The first word in the status line indicates where
the stop/start command originates.
b. The second word in the status line indicates
where the speed control originates.
c. The last part of the status line gives the present
frequency converter status. These show the
operational mode the frequency converter is in.
NOTE
In auto/remote mode, the frequency converter requires
external commands to execute functions.

6.3 Status Message Definitions Table

The next three tables define the meaning of the status
message display words.
Off
Auto On
®
is a registered Danfoss trademark
0.98A
0.000
53.2%
Remote
Ramping
Local
Stop
Running
Jogging
.
.
.
Stand by
b
c
Operation Mode
The frequency converter does not react to any
control signal until [Auto On] or [Hand On] is
pressed.
The frequency converter is controlled from the
control terminals and/or the serial communi-
cation.
1(1)
0.75kW
