FPGA registers

The Actel FPGA contains a sentence of 10 registers about which the MSC Tuttlingen specific
I/O devices can be configured.
The registers are located on the addresses:
FEh : Index
FFh : Data
The allocation is as follows:
Index
0
1
2
3
4
5
6
7
8
9
Index 0: DiskOnChip Select Control
Bit
7
6
5
4
3
2
1
0
Index 1: Fieldbus Select Control
Bit
7
6
5
4
3
2
1
0
Rev. 1.00 dated 1.7.2004
Function
DiskOnChip Select Control
Fieldbus Select Control
Fieldbus Interrupt Select
Matrix Controller Code Download Control
Watchdog Select Control
Watchdog Select Control
System Monitoring Select Control
System Monitoring Select Control
CAN/Matrix Select Control
CAN/Matrix Select Control
Function
reserved (1)
reserved (1)
DiskOnChip Base Address A17
DiskOnChip Base Address A16
DiskOnChip Base Address A15
DiskOnChip Base Address A14
reserved (0)
Disable = 0 Enable = 1
Function
reserved (1)
reserved (1)
Fieldbus Base Address A17
Fieldbus Base Address A16
Fieldbus Base Address A15
Fieldbus Base Address A14
reserved (0)
Disable = 0 Enable = 1
