IPC370T
Single-Board-Computer / Socket 370
– VIA Twister Chipset –
Operating Instructions
Issue 1.00 dated 1.7.2004
MSC Tuttlingen GmbH
Rudolf-Diesel-Straße 17
78532 Tuttlingen
Germany
Tel.
+49 7461 925-276
Fax
+49 7461 925-268
E-Mail tuttlingen@msc.de
www.msc.de/tuttlingen

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPC370T and is the answer not in the manual?

Questions and answers

Related Manuals for MSC IPC370T

Summary of Contents for MSC IPC370T

  • Page 1 IPC370T Single-Board-Computer / Socket 370 – VIA Twister Chipset – Operating Instructions Issue 1.00 dated 1.7.2004 MSC Tuttlingen GmbH Rudolf-Diesel-Straße 17 78532 Tuttlingen Germany Tel. +49 7461 925-276 +49 7461 925-268 E-Mail tuttlingen@msc.de www.msc.de/tuttlingen...
  • Page 3 Non-compliance may have an impact on the environment. Intended use The products of the "IPC & PC-based Control" series of MSC Tuttlingen GmbH may only be used for the applications described in the technical documents, and only in connection with devices or components from other manufacturers which have been approved or recommended by us.
  • Page 4 Suggestions for improvement are welcomed. EEC directive EMC 89/336/EEC The following applies to devices of the "IPC & PC-based Control" series of MSC Tuttlingen GmbH: Products which carry the CE symbol meet the requirements of the EEC directive 89/336/EEC on electromagnetic compatibility.

  • Page 5: Table Of Contents

    OI: IPC370T Contents Contents General ............................3 Characteristics ..........................3 Specifications..........................3 Block diagram ..........................6 Interfaces summary ........................7 Layout of components ........................8 Installation and Configuration....................9 Switches and jumpers........................9 2.1.1 BIOS Recovery ..........................9 2.1.2 Speaker ............................10 2.1.3...
  • Page 6 They are written for customers with prior knowledge in PC technology and automation. Purpose These operating instructions are part of the documentation of the IPC370T module. They provide service personnel and system advisors with the information required to install, commission, operate and maintain the IPC370T Single-Board-Computer inside the industrial PC.

  • Page 7: General

    General General Characteristics The IPC370T Single-Board-Computer is an especially developed CPU unit with socket 370 for the IPC product line of MSC Tuttlingen GmbH. The All-In-One board still contains additionally in the PC usual extensions besides the standard functions of a PC motherboard. These are basically two Ethernet interfaces as well as the support of flat displays.
  • Page 8 Super I/O Winbond W83977 EF 2 x RS-232 (TTL) / internal VIA VT82C686B Southbridge Parallel ECP/EPP via SETUP selectable Interface for MSC fieldbus modules or Hilscher fieldbus connection Fieldbus VIA VT82C686B Southbridge Keyboard / Mouse PS/2 keyboard interface PS/2 mouse interface...
  • Page 9 8 voltages (CPU core, CPU I/O, 3.3 V, ±5 V, ±12 V, Battery) Watchdog PIC 12C509A adjustable in BIOS Temperature see chapter "Technical data" in the operating instructions of the device in which IPC370T is installed Dimensions 265 mm x 214 mm Supply voltage selectable from different sources: Supply voltage 24 V...

  • Page 10: Block Diagram

    General OI: IPC370T Block diagram Fig. 1-1: Block diagram Page 6 of 38 Rev. 1.00 dated 1.7.2004...

  • Page 11: Interfaces Summary

    OI: IPC370T General Interfaces summary Function Type PISA 188 pin EISA slot, 180° PC/104 64 pin and 40 pin socket strip, 180°, 2.54 mm EIDE (primary) 50 pin socket strip, 90°, 2 mm (hard disk can be directly mounted) (primary) 44 pin male connection strip, 180°, without shroud, 2 mm...

  • Page 12: Layout Of Components

    General OI: IPC370T Layout of components Component side LAN2: RJ-45 LAN1: RJ-45 COM-A COM-B LPT-A COM-B LAN2 AC97 Configuration Floppy (extern) Onboard IDE disk Touch Controller TC03 Code TC03 Download COM2 / PS2 Touch COM-C COM-D DiskOnChip (ROM) PC/104 BIOS Recovery...

  • Page 13: Installation And Configuration

    OI: IPC370T Installation and Configuration Installation and Configuration Switches and jumpers 2.1.1 BIOS Recovery 82443BX Fig. 2-1: BIOS Recovery In order to force an automatic BIOS update during switch-on of the system, following steps are necessary: 1. Switch off system 2.

  • Page 14: Speaker

    Installation and Configuration OI: IPC370T 2.1.2 Speaker 82443BX Fig. 2-2: Speaker The speaker contained on the board can be switched on or switched off by this jumper. Speaker off Speaker on Page 10 of 38 Rev. 1.00 dated 1.7.2004...

  • Page 15: Onboard Ide Disk Configuration

    OI: IPC370T Installation and Configuration 2.1.3 Onboard IDE disk configuration 82443BX Fig. 2-3: Onboard IDE disk configuration With the aid of the isolated jumper (2 pin) an ATA100 cable can be simulated to the Primary IDE Interface. No ATA100 cable...

  • Page 16: Test Pins / Test Pads

    Installation and Configuration OI: IPC370T 2.1.4 Test pins / Test pads -12V +12V -5V +5V +3,3V 82443BX Fig. 2-4: Test pins / Test pads For test purposes of the usual PC supply voltages (±12V, ±5V and +3.3V) there are corresponding test points at the upper edge of the board.

  • Page 17: Memory Extension And Fsb Switching

    OI: IPC370T Installation and Configuration Memory extension and FSB switching 82443BX DIMM 2 DIMM 1 Fig. 2-5: Memory extension and FSB switching The main memory consists of two lockable DIMM sockets. It can be used standard 3.3V SDRAM modules, which correspond to the Intel specification PC100 or PC133.

  • Page 18: Battery

    Installation and Configuration OI: IPC370T Battery – 82443BX Fig. 2-6: Battery The installed lithium battery provides Real Time Clock and CMOS memory with a current, in order to permanently save system information, even if the board is separated from the supply.

  • Page 19: Replacing The Battery

    OI: IPC370T Installation and Configuration Replacing the battery When the charge is too low or the battery is empty, the data stored in the CMOS RAM (e.g. date and time) might not be accurate. Then the lithium battery must be replaced.

  • Page 20: Watchdog

    Installation and Configuration OI: IPC370T Watchdog In the BIOS set-up the following setting options are intended for the watchdog. Address: Three I/O addresses are offered for selection over which the application software can access to the watchdog. Timeout: Can be set from 400 milliseconds until 600 seconds.

  • Page 21: Resources Allocation

    OI: IPC370T Installation and Configuration Resources allocation 2.5.1 Interrupts Interrupt Function IRQ 0 Timer Output 0 IRQ 1 PS/2 Keyboard IRQ 2 (cascading) IRQ 3 free / COM2 IRQ 4 free / COM1 IRQ 5 Free IRQ 6 free / Floppy Controller...

  • Page 22: Memory

    Installation and Configuration OI: IPC370T 2.5.3 Memory Upper Memory Used for Available Function C0000h .. CFFFFh 64 KB VGA BIOS D0000h .. DBFFFh ISA Bus or Shadow RAM DC000h .. DFFFFh USB Buffer E0000h .. FFFFFh System BIOS Page 18 of 38...

  • Page 23: Isa I/O

    OI: IPC370T Installation and Configuration 2.5.4 ISA I/O Address on IPC370T Function 0000 - 001F ü DMA Controller 1 0020 - 0021 ü Interrupt Controller 1 0024 - 0025 ü Interrupt Controller 1 0028 - 0029 ü Interrupt Controller 1 002C - 002D ü...
  • Page 24 Installation and Configuration OI: IPC370T Address on IPC370T Function 0258 - 0259 (ü) CAN/Matrix 025A - 025B (ü) CAN/Matrix 0260 - 0273 (ü) Audio / SoundBlaster8/16 0270 (ü) Watchdog 0278 - 027F Parallel Port 2 0280 - 0287 (ü) System Monitoring (W83782) 0280 - 0293 (ü)

  • Page 25: Fpga Registers

    OI: IPC370T Installation and Configuration FPGA registers The Actel FPGA contains a sentence of 10 registers about which the MSC Tuttlingen specific I/O devices can be configured. The registers are located on the addresses: FEh : Index FFh : Data...
  • Page 26 Installation and Configuration OI: IPC370T Index 2: Fieldbus Interrupt Select Function reserved (0) reserved (0) reserved (0) reserved (0) Fieldbus Interrupt Select Bit 3 Fieldbus Interrupt Select Bit 2 Fieldbus Interrupt Select Bit 1 Fieldbus Interrupt Select Bit 0 Index 3:...
  • Page 27 OI: IPC370T Installation and Configuration Index 6: System Monitoring Select Control Function System Monitoring Chip Base Address A7 System Monitoring Chip Base Address A6 System Monitoring Chip Base Address A5 System Monitoring Chip Base Address A4 System Monitoring Chip Base Address A3...

  • Page 28: Driver Installation

    Installation and Configuration OI: IPC370T Driver installation All drivers, that you need for installation, you will find in the directory "drivers" on the hard disk of your industrial computer. Example: "c:\drivers\Ethernet\……." You will also find a copy of the system directory of the operating system CD on the hard disk.

  • Page 29: Hardware Interfaces

    OI: IPC370T Hardware Interfaces Hardware Interfaces COM-A D-SUB connector, 9 pin 1 2 3 4 5 6 7 8 9 Signal RxD# TxD# 82443BX Fig. 3-1: COM-A COM-B D-SUB connector, 9 pin or male connection strip, 10 pin, with shroud, 2.54 mm...

  • Page 30: Com-C / Com-D

    Hardware Interfaces OI: IPC370T COM-C / COM-D Socket strip, 16 pin, 2.54 mm COM-C COM-D Signal Signal VCCN5V VCCN12V VCC12V 82443BX DCD# DSR# RTS# CTS# DTR# VCC5V Fig. 3-3: COM-C / COM-D Page 26 of 38 Rev. 1.00 dated 1.7.2004...

  • Page 31: Lpt-A

    OI: IPC370T Hardware Interfaces LPT-A D-SUB socket, 25 pin Signal STROBE# LPT D0 LPT D1 LPT D2 LPT D3 LPT D4 LPT D5 LPT D6 LPT D7 ACK# BUSY SLCT ALF# ERROR# INIT# SLCTIN# 82443BX Fig. 3-4: LPT-A Rev. 1.00 dated 1.7.2004...

  • Page 32: Crt - Monitor

    Hardware Interfaces OI: IPC370T CRT – Monitor HD-SUB socket, 15 pin 5 4 3 2 1 15 14 13 12 11 Signal GREEN BLUE VCC5V Fused VCC5V Fused 82443BX RESERVED DDC DAT HSYNC VSYNC DDC CLK Fig. 3-5: CRT – Monitor...

  • Page 33: Keyboard And Mouse

    OI: IPC370T Hardware Interfaces Keyboard and mouse 2 x MiniDIN, 6 pin (two-in-one) Mouse Keyboard • Keyboard Signal KBDAT MDAT VCC5V Fused KBCLK MCLK • Mouse Signal MDAT 82443BX n.c. VCC5V Fused MCLK n.c. Fig. 3-7: Keyboard and mouse USB Type A Connector (two-in-one), 2 x 4 pin...

  • Page 34: Primary Ide (Internal) - Onboard

    Hardware Interfaces OI: IPC370T Primary IDE (internal) – Onboard Socket strip, 50 pin, 2 mm, 90° (Hard disk can be directly mounted) Signal Signal Konf1 Konf2 Konf3 Konf4 n.c. n.c. /IDE-RESET DATA7 DATA8 DATA6 DATA9 DATA5 DATA10 DATA4 DATA11 DATA3...

  • Page 35: Primary Ide (External)

    OI: IPC370T Hardware Interfaces 3.10 Primary IDE (external) Male connection strip, 44 pin, 2 mm Signal Signal /IDE-RESET DATA7 DATA8 DATA6 DATA9 DATA5 DATA10 DATA4 DATA11 DATA3 DATA12 DATA2 DATA13 DATA1 DATA14 DATA0 DATA15 n.c. DRQ0 /IDEIOW /IDEIOR IORDY +5V pull up...

  • Page 36: Secondary Ide

    Hardware Interfaces OI: IPC370T 3.11 Secondary IDE Male connection strip, 40 pin, with shroud, 2.54 mm Signal Signal /IDE-RESET DATA7 DATA8 DATA6 DATA9 DATA5 DATA10 DATA4 DATA11 DATA3 DATA12 DATA2 DATA13 DATA1 DATA14 DATA0 DATA15 n.c. DRQ0 /IDEIOW /IDEIOR IORDY...

  • Page 37: Floppy (Internal)

    OI: IPC370T Hardware Interfaces 3.12 Floppy (internal) Male connection strip, 34 pin, with shroud, 2.54 mm Signal Signal DENSEL# n.c. DRATE0 /INDEX# MOTOR1# DRVSEL2# DRVSEL1# MOTOR2# STEP# WRDATA# 82443BX WR GATE# TRACK 0# WRPROTECT# RDDATA# HEADSEL DISKCHANGE# Fig. 3-12: Floppy (internal) Rev.

  • Page 38: Floppy (External)

    Hardware Interfaces OI: IPC370T 3.13 Floppy (external) Male connection strip, 40 pin, with shroud, 2.54 mm Signal Signal VCC5V Fused VCC5V Fused DENSEL# n.c. n.c. /INDEX# MOTOR1# DRVSEL2# DRVSEL1# MOTOR2# STEP# WRDATA# WR GATE# TRACK 0# 82443BX WRPROTECT# RDDATA# HEADSEL DISKCHANGE# n.c.

  • Page 39: Fig. 3-14: Pc/104

    OI: IPC370T Hardware Interfaces 3.14 PC/104 Socket strip, 64 pin und 40 pin, 2.54 mm — — /IOCHCK SBHE# MEMS16# RESET LA23 IOCS16# LA22 IRQ10 IRQ9 LA21 IRQ11 /MEMR LA20 IRQ12B DRQ2 LA19 IRQ15 -12V LA18 IRQ14 /0WS LA17 DACK0#...

  • Page 40: Fieldbus

    Hardware Interfaces OI: IPC370T 3.15 Fieldbus Socket strip, 40 pin, 2.54 mm Signal Signal VCC5V n.c. SMEMW# SMEMR# n.c. FB_CS# SA10 SA11 SA212 VCC5V 82443BX SA13 RSTDRV n.c. n.c. FB_INT# n.c. n.c. FB_BUSY n.c. n.c. Fig. 3-15: Fieldbus 3.16 Fans Male connection strip, 3 pin, coded, 2.54 mm –...

  • Page 41: Temperature Alarm

    OI: IPC370T Hardware Interfaces 3.17 Temperature alarm Male connection strip, 4 pin, coded, 2.54 mm Signal VCC5V Alarm 82443BX VCC12V Fig. 3-17: Temperature alarm 3.18 Power out Male connection strip, 4 pin, coded, 2.54 mm – 4x Signal VCC5V 82443BX VCC12V Fig.

  • Page 42: Power In

    Hardware Interfaces OI: IPC370T 3.19 Power in Terminal strip, 3 pin Signal VCC12V 82443BX VCC5V Fig. 3-19: Power in 3.20 External battery Male connection strip, 4 pin, 2.54 mm Signal n.c. n.c. 82443BX VBAT Fig. 3-20: External battery Page 38 of 38...
