OI: IPC370T
1.4

Interfaces summary

Function
PISA
PC/104
EIDE (primary)
(primary)
(secondary)
Floppy (internal)
(external)
Serial (COM-A)
(COM-B – external)
(COM-B – internal)
(COM-C)
(COM-D)
Parallel (LPT-A)
VGA (CRT)
Ethernet
Keyboard
Mouse
USB
Fieldbus
Fan (3x)
Temperature alarm
Power output (4x)
+5V/+12V input
External battery
Note:
All interfaces are placed on the component side.
Rev. 1.00 dated 1.7.2004
Type
188 pin EISA slot, 180°
64 pin and 40 pin socket strip, 180°, 2.54 mm
50 pin socket strip, 90°, 2 mm (hard disk can be directly mounted)
44 pin male connection strip, 180°, without shroud, 2 mm
40 pin male connection strip, 180°, with shroud, 2.54 mm
34 pin male connection strip, 180°, with shroud, 2.54 mm
40 pin male connection strip, 180°, with shroud, 2.54 mm
9 pin D-SUB connector, 90°
9 pin D-SUB connector, 90°
10 pin male connection strip, 180°, with shroud, 2.54 mm
16 pin socket strip, 180°, 2.54 mm
16 pin socket strip, 180°, 2.54 mm
25 pin D-SUB socket, 90°
15 pin HD-SUB socket, 90°
2 x RJ-45 with integrated LEDs, 90°
6 pin MiniDIN socket, 90°
6 pin MiniDIN socket, 90°
2 x 4 pin USB type A connector (two-in-one), 90°
40 pin socket strip, 180°, 2.54 mm
3 pin male connection strip, 180°, coded, 2.54 mm
4 pin male connection strip, 180°, coded, 2.54 mm
4 pin male connection strip, 180°, coded, 2.54 mm
3 pin terminal strip, 90°
4 pin male connection strip, 2.54 mm
General
Page 7 of 38
