Communication ports

COM1
IR - Basic
COM2
GSM/GPRS
module – Optional
COM3
IRIG-B module –
Optional
ETHERNET/USB
module –
IRIG-B
IRIG-B module –
Optional
10/100 Base T
ETHERNET/USB
module - Optional
USB
ETHERNET/USB
module - Optional
Appendix: Technical Specifications
Front panel
Optical Communication port
Max. Baud rate
Protocols
Plug-in modules isolated communication port
GSM/GPRS module
Max. Baud rate
Protocols
Isolation
GSM/GPRS module antenna connector
Plug-in modules isolated communication port
Versatile RS232/RS485
Max. Baud rate
Isolation
Protocols
Terminals for wires size
Isolation
Time code signal
Signal Level
Connector Type
Recommended cable
Recommended GPS time code generator
Plug-in modules network communication port
Wired LAN communication port
Ethernet port Baud rate
Protocols
ETH port Isolation
ETH connector
Plug-in modules network communication port
USB communication port
USB port Baud rate
USB port Isolation
Protocols
USB connector
IEC 62056-21
19.200 kb/s
Modbus RTU/ASCII and
DNP3.0
Field installable
Quad Band GPRS
class10
115.2 kb/s
Modbus RTU/TCP and
DNP3.0/TCP
4 KVAC @ 1mn
SMA
Field installable
115.2 kb/s
4 KVAC @ 1mn
Modbus RTU/ASCII and
DNP3.0
2
5 x 2.5 mm
4 KVAC @ 1mn
Unmodulated (pulse-width
coded)
Unbalanced 5V
BNC
51Ohm low loss -
RG58A/U (Belden 8219 or
equivalent), TNC
connector
Masterclock GPS-200A
Field installable
IEEE 802.3
10/100 Mb/s, auto-
negotiation
Modbus/TCP or
DNP3.0/TCP protocols,
up to five non-intrusive
simultaneous
connections, Telnet
service port
3 KVAC @ 1mn
Standard RJ-45
Field installable
Full speed Device
12 Mb/s
1.5 KVAC @ 1mn
Modbus RTU/ASCII and
DNP3.0
Mini-USB type B
