Chapter 3 Display Operations
Prt.1
Prot
rtu
Series PM172 Powermeters
Label Parameter
U1.rt V1-V3 voltage 0.900 to 1.100
U2.rt transformer
U3.rt ratio correction
factor
-600 to 600
U1.AG V1-V3
U2.AG transformer (-2700 to 2700 with
U3.AG phase angle V13.7X.XX)
error, minutes
C1.rt I1-I3 current 0.900 to 1.100
C2.rt transformer
C3.rt ratio correction
factor
-600 to 600
C1.AG I1-I3
C2.AC transformer (-2700 to 2700 with
C3.AG phase angle V13.7X.XX)
error, minutes

Communication Ports

These two menus allow you to configure parameters for communication
ports COM1 and COM2. To enter the menu, select "Prt.1" for COM1 or
"Prt.2" for COM2 from the Main menu, and then press the ENTER button.
To select a setup option:
1. Press the SELECT button to activate the middle window.
2. Use the UP and DOWN arrow buttons to scroll to the
desired option.
To change the option:
1. Press the SELECT button to activate the lower window.
2. Use the UP and DOWN arrow buttons to select the
desired option.
3. Press ENTER to confirm your changes and to store your
new setting, or press ESC to discard changes.
To exit the menu, press ESC.
The following tables list available port options.
COM1 Settings
Label Parameter
Prot Communications
protocol
1
rS
Port interface
Options Default
1.000
0
1.000
0
Options Default
ASCII = SATEC ASCII Modbus
2
rtu = Modbus RTU RTU
2
dnP3 = DNP3
dtE = DTE
PrFb = Profibus DP
232 = RS-232 Depends
485 = RS-485 on the
422 = RS-422 order
dial = Dial-up Modem
Eth.= Ethernet
PrFb = Profibus DP
Menu Operations
Description
The ratio of the true
transformer ratio to the
marked ratio.
The phase
displacement, in
minutes, between the
primary and secondary
values. The phase angle
of a voltage transformer
is positive when the
secondary value leads
the primary value.
The ratio of the true
transformer ratio to the
marked ratio.
The phase
displacement, in
minutes, between the
primary and secondary
values. The phase angle
of a current transformer
is positive when the
secondary value leads
the primary value.
Description
The communications
protocol supported by
the port
For non-serial interfaces
- not changeable;
automatically detected
by the meter
45
