F i g u r e 2 0 : M i n i - U S B de v i c e C o n n e c t i o n

To prevent potential differences between the Personal Computer (PC) USB port and

the EM720 USB device port, it is recommended to use a galvanic isolated USB

adaptor before connecting the EM720 USB port to a Personal Computer (PC), or to

use battery powered PC.

Chapter 2 Installation
