Commissioning
5.3.5 Changing Parameter Settings
View changes
Quick Menu Q5 - Changes Made lists all parameters
changed from default settings.
•
The list shows only parameters which have been
changed in the current edit-setup.
•
Parameters which have been reset to default
values are not listed.
•
The message 'Empty' indicates that no
parameters have been changed.
Changing settings
Parameter settings can be accessed and changed from the
[Quick Menu] or from the [Main Menu]. The [Quick Menu]
only gives access to a limited number of parameters.
1. Press [Quick Menu] or [Main Menu] on the LCP.
▲ ▼
2.
Press [ ] [ ] to browse through the parameter
groups, press [OK] to select a parameter group.
▲ ▼
3.
Press [ ] [ ] to browse through the parameters,
press [OK] to select a parameter.
▲ ▼
4.
Press [ ] [ ] to change the value of a parameter
setting.
5.
Press [◄] [►] to shift digit when a decimal
parameter is in the editing state.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter "Status", or
press [Main Menu] once to enter "Main Menu".
5.3.6 Restoring Default Settings
NOTICE
Risk of loosing programming, motor data, localisation,
and monitoring records by restoration of default
settings. To provide a backup, upload data to the LCP
before initialisation.
Restoring the default parameter settings is done by initiali-
sation of the frequency converter. Initialisation is carried
out through 14-22 Operation Mode (recommended) or
manually.
•
Initialisation using 14-22 Operation Mode does not
reset frequency converter settings such as
operating hours, serial communication selections,
personal menu settings, fault log, alarm log, and
other monitoring functions.
•
Manual initialisation erases all motor,
programming, localisation, and monitoring data
and restores factory default settings.
®
VLT AQUA Drive FC 202 Operating Instructions
Recommended initialisation procedure, via
14-22 Operation Mode
1.
2.
3.
4.
5.
Default parameter settings are restored during start-up.
This may take slightly longer than normal.
6.
7.
Manual initialisation procedure
1.
2.
Factory default parameter settings are restored during
start-up. This may take slightly longer than normal.
Manual initialisation does not reset the following frequency
converter information:
•
•
•
•

5.4 Basic Programming

5.4.1 Commissioning with SmartStart

The SmartStart wizard enables fast configuration of basic
motor and application parameters.
•
•
•
NOTICE
Motor data are required for the SmartStart setup. The
required data are normally available on the motor
nameplate.

MG20MA02 - Rev. 2013-10-29

Press [Main Menu] twice to access parameters.
Scroll to 14-22 Operation Mode and press [OK].
Scroll to Initialisation and press [OK].
Remove power to the unit and wait for the
display to turn off.
Apply power to the unit.
Alarm 80 is displayed.
Press [Reset] to return to operation mode.
Remove power to the unit and wait for the
display to turn off.
Press and hold [Status], [Main Menu], and [OK] at
the same time while applying power to the unit
(approximately 5 s or until audible click and fan
starts).
15-00 Operating hours
15-03 Power Up's
15-04 Over Temp's
15-05 Over Volt's
At first power up or after initialisation of the
frequency converter, SmartStart starts by itself.
Follow on-screen instructions to complete
commissioning of the frequency converter.
Always reactivate SmartStart by selecting Quick
Menu Q4 - SmartStart.
For commissioning without use of the SmartStart
wizard, refer to 5.4.2 Commissioning via [Main
Menu] or the Programming Guide.
