Specifications
Speed accuracy (open loop)
All control characteristics are based on a 4-pole asynchronous motor
Control card performance
Scan interval
Control card, USB serial communication
USB standard
USB plug
CAUTION
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB connection is not galvanically isolated from protection earth. Use only isolated laptop/PC as connection to the
USB connector on the frequency converter, or an isolated USB cable/converter.

8.7 Connection Tightening Torques

Enclosure Mains
A2 1.8
A3 1.8
A4 1.8
A5 1.8
B1 1.8
B2 4.5
B3 1.8
B4 4.5
C1 10
1)
C2 14/24
C3 10
C4 1)
14/24
Table 8.12 Tightening of Terminals
For different cable dimensions x/y, where x ≤ 95 mm
1)
®
VLT AQUA Drive FC 202 Operating Instructions
Torque [Nm]
DC
Motor
connection
1.8 1.8
1.8 1.8
1.8 1.8
1.8 1.8
1.8 1.5
4.5 3.7
1.8 1.8
4.5 4.5
10 10
1)
14/24 14
10 10
1) 14
14/24
and y ≥ 95 mm
2
MG20MA02 - Rev. 2013-10-29
30-4000 rpm: Maximum error of ±8 RPM
USB type B "device" plug
Brake Ground
1.8 3
1.8 3
1.8 3
1.8 3
1.5 3
3.7 3
1.8 3
4.5 3
10 3
14 3
10 3
14 3
2
.
5 ms
1.1 (Full speed)
Relay
8 8
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
