Commissioning
The SmartStart configures the frequency converter in 3
phases, each consisting of several steps, see Table 5.6.
1 Basic Programming
2 Application Section
5 5
3 Water and Pump Features
Table 5.6 SmartStart, Setup in 3 Phases

5.4.2 Commissioning via [Main Menu]

Recommended parameter settings are intended for start-
up and checkout purposes. Application settings may vary.
Enter data with power ON, but before operating the
frequency converter.
1. Press [Main Menu] on the LCP.
2. Press the navigation keys to scroll to parameter
group 0-** Operation/Display and press [OK].
Illustration 5.2 Main Menu
3. Press navigation keys to scroll to parameter
group 0-0* Basic Settings and press [OK].
Illustration 5.3 Operation/Display
4. Press navigation keys to scroll to 0-03 Regional
Settings and press [OK].
24
Phase Comment
Program e.g. motor data
Select and program
appropriate application:
•
Single pump/motor
•
Motor alternation
•
Basic cascade control
•
Master/follower
Go to water and pump
dedicated parameters
1107 RPM 3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
0.0% 0.00A
Operation / Display
0-0 Basic Settings
*
0-1 * Set-up Operations
0-2 * LCP Display
0-3 * LCP Custom Readout
®
VLT AQUA Drive FC 202 Operating Instructions
Illustration 5.4 Basic Settings
5.
6.
7.
8.
9.
10.
11.
1 (1)
12.
13.
14.

5.4.3 Asynchronous Motor Setup

Enter the motor data in parameter 1-20 Motor Power [kW]
or 1-21 Motor Power [HP] to 1-25 Motor Nominal Speed. The
information can be found on the motor nameplate.
1.
1(1)
0- ** 2.
3.
4.
5.
MG20MA02 - Rev. 2013-10-29
0.0% 0.00A
Basic Settings
0-03 Regional Settings
[0] International
Press navigation keys to select [0] International or
[1] North America as appropriate and press [OK].
(This changes the default settings for a number
of basic parameters).
Press [Main Menu] on the LCP.
Press the navigation keys to scroll to
0-01 Language.
Select language and press [OK].
If a jumper wire is in place between control
terminals 12 and 27, leave 5-12 Terminal 27 Digital
Input at factory default. Otherwise, select No
Operation in 5-12 Terminal 27 Digital Input. For
frequency converters with an optional bypass, no
jumper wire is required between control
terminals 12 and 27.
3-02 Minimum Reference
3-03 Maximum Reference
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-13 Reference Site. Linked to Hand/Auto Local
Remote.
1-20 Motor Power [kW] or 1-21 Motor Power [HP]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1(1)
0-0
*
