Scope And Field Of Service Manual; Service Policy For Fcd 300; In General; Field Service - Danfoss FCD300 Service Manual

1.

Scope and field of service manual

This Service manual is made with the purpose to help when doing technical service on the
FCD300 in the field.
The service manual will be updated continuous to be able to improved the service and
always be up-to-date.
Comment and proposal to this service manual, please send an e-mail to DD global hotline:
Drives_Hotline@danfoss.com, with your comment.
2.

Service Policy for FCD 300

2.1.

In General

The FCD 300 is a non-repairable product.
Depending on economical or practical service situation repairs can be proceeded by
exchange of complete units or exchange the control card.
2.2.

Field Service

- Repair in the field
- Factory repair
NB: The complete service policy can be found on the Global Service Page.
3.

Installation, programming and basic fault tracing

For installation, programming and basic fault tracing use the Design Guide MG.04.A3.xx
4.

Replacement

Only repair option is by replacing the control card, complete electronic part or exchange
damage parts in the installation box. If the installation box, it self, is damage, then a new
have to be ordered through commercial department.
Replacing the control card could repair the electronic part.
NB
Always use ESD protection when change the control card or remove the plastic part
from the electronic part.
Release 01/2003
Revise 08/01/2003 by DD Service Manager, Steffen Sundbæk
Service Manual FCD 300
Exchange the drive (only the electronic part, not the installation parts)
to new or exchange the control card.
No factory repair.
4
