Danfoss VLT AQUA Drive FC 202 Operating Instructions Manual page 15

Electrical Installation
1
9
10
L1
L2
L3
PE
Illustration 4.2 EMC-compliant Electrical Connection
1 PLC
2 Frequency converter
3 Output contactor
4 Grounding rail (PE)
5 Cable insulation (stripped)
Table 4.1 Legend to Illustration 4.2
NOTICE
EMC INTERFERENCE!
Use screened cables for motor and control wiring, and separate cables for input power, motor wiring and control
wiring. Failure to isolate power, motor and control cables can result in unintended behaviour or reduced performance.
Minimum 200 mm (7.9 in) clearance between power, motor and control cables is required.
®
VLT AQUA Drive FC 202 Operating Instructions
2
8
6 Cable gland
7 Motor, 3-phase and PE
8 Mains, 3-phase and reinforced PE
9 Control wiring
10
Equalising min. 16 mm
MG20MA02 - Rev. 2013-10-29
6
3
4
7
2
(0.025 in)
4 4
5
U
V
W
PE
13
