Blocked airflow around the frequency converter
•
Damaged heatsink fan
•
Dirty heatsink
This alarm is based on the temperature measured by the
heatsink sensor mounted inside the IGBT modules
Troubleshooting
•
Check fan resistance
•
Check soft charge fuses
•
IGBT thermal sensor
ALARM 30, Motor phase U missing
Motor phase U between the frequency converter and the
motor is missing.
Remove power from the frequency converter and check
motor phase U.
ALARM 31, Motor phase V missing
7 7
Motor phase V between the frequency converter and the
motor is missing.
Remove power from the frequency converter and check
motor phase V.
ALARM 32, Motor phase W missing
Motor phase W between the frequency converter and the
motor is missing.
Remove power from the frequency converter and check
motor phase W.
ALARM 33, Inrush fault
Too many power-ups have occurred within a short time
period. Let the unit cool to operating temperature.
WARNING/ALARM 34, Fieldbus communication fault
The fieldbus on the communication option card is not
working.
WARNING/ALARM 36, Mains failure
This warning/alarm is only active if the supply voltage to
the frequency converter is lost and 14-10 Mains Failure is
NOT set to [0] No Function. Check the fuses to the
frequency converter and mains power supply to the unit.
ALARM 38, Internal fault
When an internal fault occurs, a code number defined in
the Table 7.6 is displayed.
Troubleshooting
•
Cycle power
•
Check that the option is properly installed
•
Check for loose or missing wiring
Contact the Danfoss supplier or service department if
required. Note the code number for further trouble-
shooting directions.
38
®
VLT AQUA Drive FC 202 Operating Instructions
No.
0
256-258
512
513
514
515
516
517
518
519
783
1024-1279
1281
1282
1283
1284
1299
1300
1301
1302
1315
1316
1317
1318
1379
1380
1381
1382
1536
1792
2049
2064-2072
2080-2088
2096-2104
2304
MG20MA02 - Rev. 2013-10-29
Text
Serial port cannot be initialised. Contact
theDanfoss supplier or Danfoss Service
Department.
Power EEPROM data is defective or too old.
Control board EEPROM data is defective or too
old.
Communication time out reading EEPROM data.
Communication time out reading EEPROM data.
Application oriented control cannot recognize the
EEPROM data.
Cannot write to the EEPROM because a write
command is on progress.
Write command is under time out.
Failure in the EEPROM.
Missing or invalid barcode data in EEPROM.
Parameter value outside of min/max limits.
A centelegram that has to be sent couldn't be
sent.
Digital signal processor flash timeout.
Power micro software version mismatch.
Power EEPROM data version mismatch.
Cannot read digital signal processor software
version.
Option SW in slot A is too old.
Option SW in slot B is too old.
Option SW in slot C0 is too old.
Option SW in slot C1 is too old.
Option SW in slot A is not supported (not
allowed).
Option SW in slot B is not supported (not
allowed).
Option SW in slot C0 is not supported (not
allowed).
Option SW in slot C1 is not supported (not
allowed).
Option A did not respond when calculating
platform version.
Option B did not respond when calculating
platform version.
Option C0 did not respond when calculating
platform version.
Option C1 did not respond when calculating
platform version.
An exception in the application oriented control is
registered. Debug information written in LCP.
DSP watchdog is active. Debugging of power part
data, motor oriented control data not transferred
correctly.
Power data restarted.
H081x: option in slot x has restarted.
H082x: option in slot x has issued a powerup-wait.
H983x: option in slot x has issued a legal
powerup-wait.
Could not read any data from power EEPROM.
